27

4 CONFIGURATION MODE…

Note. Settings for options P, S and T are only available if the

appropriate option board is fitted.

Fig. 4.8 Digital Function and Serial Communications Configurations

P 0000 r 0000

S 0000 t 0000

Display Baud Rate, 2/4 Wire

0Off

1 2400, 2 Wire

2 2400, 4 Wire

3 9600, 2 Wire

4 9600, 4 Wire

S – Serial Communication

Configuration

Display

0 None

1 Odd

2 Even

T – Serial Communication

Parity

Display

0 None

1 Totalizer Reset

2 Totalizer Stop/Go

3 Average, Max/Min Reset

4 Front Panel Lockout

5 Alarm Acknowledge

P – Digital Input Function

Display

0 0 seconds

1 1 second

2 2 seconds

5 5 seconds

A 10 seconds

B 20 seconds

C 40 seconds

D 60 seconds

R – Analog Input Filter
