IN1403 User’s Manual
17
Display Type Suggested Optimal /
Native Resolution
Suggested
Refresh Rate
Comments
CRT Displays
15” Data Monitor 800 x 600 / 1024 x 768 72 Hz / 75 Hz
17” Data Monitor 1024 x 768 72 Hz / 75 Hz
19” / 21” Data Monitor 1024 x 768 / 1280 x 1024 72 Hz – 85 Hz
27 – 42” Presentation Monitor 800 x 600 / 1024 x 768 72 Hz / 75 Hz
32 – 38” HDTV Display (16:9) 1024 x 768 / 1280 x 720 72 Hz / 75 Hz
Data Projector or Retro Display
with 7” CRTs 800 x 600 / 1024 x 768 72 Hz – 85 Hz
Data Projector or Retro Display
with 9” CRTs 1024 x 768 / 1280 x 1024 72 Hz – 85 Hz
Projectors, Flat Panel and Plasma Display Devices
DMD / DLP Projectors
800 x 600 / 1024 x 768 /
1280 x 720 / 1280 x 1024 60 Hz
Check Native
Resolution of Display.
For 848 x 600, set
scaler to 800 x 600.
LCOS / D-ILA Projectors 1365 x 1024 60 Hz
LCD Projectors
800 x 600 / 1024 x 768 /
1280 x 1024 / 1365 x 768
60 Hz
Check Projector's
Native Resolution.
Very old units may be
640 x 480.
LCD 14” / 15” Flat Panel Display 1024 x 768 60 Hz
LCD 18” Flat Panel Display 1280 x 1024 60 Hz
LCD 28" Flat Panel Display 1280 x 768 60 Hz
Plasma Display 40” (4:3) 640 x 480 60 Hz
Plasma Display 42” (16:9)
852 x 480 / 1024 x 768 /
1280 x 768 60 Hz
Fujitsu / Sony 42”
Plasmas with
1024 x 1024: Set Scaler
to 1024 x 768
Plasma Display 50” / 60" (16:9) (Boxlight
/ Eizo / LG / Pioneer / Runco / Sharp /
Viewsonic)
1280 x 768 56 / 60 / 65 Hz
Pioneer PDP-505HD:
Use 56 Hz
Plasma Display 50” / 60” (16:9) (Fujitsu /
JVC / Luce / Marantz / NEC / Panasonic /
RCA / Runco / Samsung / Toshiba)
1365 x 768 60 Hz
NEC 50": Set Sync
Format to RGBHV++
