PARK BRAKE GROUP
- 13 -
Item
Part No.
Description
Qty.
1 1-652073-03 Crank Wldmt, Brake...............................1
2 3272-10 Pin, Cotter 1/8 x 3/4...............................2
3 1-633131 Yoke ......................................................4
4 1-808285 Pin, Clevis 3/8 x 1 1/8 ............................2
5 3219-3 Nut, 3/8-24.............................................8
6 103-0356 Rod, Brake.............................................2
7 1-653068 Spacer (Long) 46” & 50” Deck ...............4
6
1-653380 Spacer (Long) 56” Deck ........................4
8 3257-42 Woodruff Key, 5/16 x 1 ..........................2
9 325-12 Screw, HH 1/2-13 x 3, 46” & 50”.............8
325-17 Screw, HH 1/2-13 x 4, 56”......................8
10 103-9761 Band, Brake...........................................2
11 103-0590 Hub & Drum W/Studs, Plated ................2
1-633926 Stud, Wheel...........................................8
12 1-809036 Nut, Slotted 1.00-20...............................2
13 1-806800 Pin, Cotter 9/64 x 1 1/2 ..........................2
14 103-0374 Retainer, Brake Band.............................2
15 103-0384 Spacer ...................................................6
16 322-9 Screw, 5/16-18 x 1 3/4 ...........................6
17 32151-48 Ring, Retaining ......................................1
Item
Part No.
Description
Qty.
18 1-633144 Pin, Trunion...........................................2
19 3256-4 Washer, 3/8 Std.....................................4
20 1-633454 Spring, Brake Rod .................................2
21 323-4 Screw, 3/8-16 x 3/4................................9
22 103-4630 Asm, Lever (1-653074-03) W/Grip.........1
23 1-633268 Grip, Brake Lever...................................1
24 1-653069 Spacer(Short) 46”& 50” Deck.................4
6
1-653381 Spacer(Short) 56” Deck.........................4
25 109-5618 Nut, Square Special 1/2-13....................8
26 103-2399 Pin, Spring Clevis ..................................2
27 1-633102 Bearing, Flange .....................................4
28 3290-357 Nut, Whizlock 3/8-16 .............................8
29 103-3116 Shaft Wldmt, Brake ...............................1
30 1-653061 Linkage, Brake Handle ..........................1
31 1481 Zerk, Grease..........................................2
32 98-5975 Washer, Disc Spring 3/8........................1
33 1-523157 Washer, Spacer.....................................2
34 103-0352-03 Bracket, Brake 46” & 50” .......................2
6
103-0353-03 Bracket, Brake 56”.................................2
Exmark black touch up spray paint – gloss black.
6 Not Illustrated.
