5.17.2 Setting the Reset Peak Rate
To reset the Peak Rate field to zero, proceed as follows:
1. Use the arrow keys to highlight the Reset Peak field for the selected
port.
2. Press the SPACE bar to select YES.
3. Use the arrows keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message “SAVED OK” displays and the Time
Since Peak field is also reset.
5.18 DEVICE STATISTICS MENU SCREEN
The Device Statistics Menu screen, Figure 5-23, provides access to
screens that allow the user to obtain switch statistics about frame traffic
through each interface and view operating statistics about each interface.
To access the Device Statistics Menu from the Device Menu screen, use
the arrow keys to highlight the DEVICE STATISTICS menu item and
press ENTER. The Device Statistics Menu screen displays.
NOTE
The Switch Statistics menu item will only display if the
operational mode of the device has been set to 802.1D
SWITCHING or 802.1Q SWITCHING. Refer to Section 5.7.9
for instructions on configuring the device to operate in this
mode.
