12 Tour Menu
The Tour menu provides access to preset tours that are customized to run a sequence of user
selected presets.
12.1 Setting a Tour
The AutoDome Easy is designed to set up to four (4) customized sequences of preset shots
covered by the AutoDome Easy camera. To set a tour, do the following:
1. Press ON + 4 + 6 + ENTER to access the main menu.
2. Select TOUR.
3. Select desired tour number (1-4).
4. To edit the title see Section 11: Creating Titles.
5. Select the DWELL TIME field.
6. Press the joystick right to increase the time or left to decrease the time.
7. Select the ========== field, to set the sequence of preset shots. Twist the joystick knob.
A number is displayed and the cursor starts blinking indicating it is in edit mode.
8. Twist the joystick to the right or left to begin scrolling through the saved presets. Twist
the joystick right to go forward or twist the joystick left to go backwards.
9. Press the joystick to the right after reaching the desired number. The number stops blink-
ing. The next sequential number is changed to blinking = =, twist the joystick and repeat
step 8.
10. When satisfied with the preset tour, select SAVE AND EXIT. To exit without saving, select
EXIT W/O SAVE.
MAIN MENU TOUR MENU
PRESET TOUR: 1
TOUR TITLE: ==========
AUTO PAN DWELL TIME: 05 SEC
SECTOR 01 03 05 = = = =
ALARM = = = = = = = =
CAMERA SETUP DELETE DATA
DOME SETUP SAVE AND EXIT
EXIT EXIT W/O SAVE
Menu Description
Tour Accesses a sequence of preset shots combined to provide a pre-programmed tour
of the area covered by an AutoDome Easy camera.
Title Controls a 10-character scene name which is displayed when the AutoDome Easy
runs the preset tour (must be user defined via the Title OSD).
Dwell Time Allows a range of 5-99 sec. The camera pauses at each preset for the specified
amount of time. Default is 5.
01 03 05 = = = =
= = = = = = = =
Controls a customized sequence of preset shots which are combined to provide a
pre-programmed tour of the area covered by an AutoDome Easy camera.
Delete Data Deletes the previously saved tour.
Save and Exit Saves the data and exits the menu.
Exit W/O Save Exits the menu without saving the data.
