IP Standard ACLs
The switch supports up to 127 IP ACLs (standard and extended). IP Standard ACLs are num-
bered from 1-1000. Use IP Standard ACLs to filter traffic using source IP address/network
mask and destination IP address/network/mask.
To create an IP Standard ACL:
To delete an IP Standard ACL:
IP Extended ACLs
The switch supports up to 127 IP ACLs (standard and extended). IP Extended ACLs are num-
bered from 1001-65535. Use IP Extended ACLs to filter traffic using the following criteria:
Source IP address/network mask
Destination IP address/network mask
IP protocol number or name as shown in Table 6-1
TCP/UDP application ports, as shown in Table 6-2 on page 97
TCP flags
ICMP message code and type
Type of Service (TOS) value
DSCP value
RS G8000 (config)# access-list ip standard 1
RS G8000 (config-std-nacl)#
RS G8000 (config)# no access-list ip standard 1
RS G8000 (config)#
