CONNECTING AND CONFIGURING YOUR MODEM ROUTER
1.2 Replacing an Existing Modem or Modem Router
Follow these steps if you currently have a modem or a modem router
that you will be replacing with your new Router.
Important: Please unplug the power adapter of your old modem from
your wall outlet first.
1. Unpack your new Router from the box and place it next to
your old modem. Raise the Router’s antennas. Unplug your old
modem’s power cord.
2. Locate the cable that connects your old modem to your computer.
Unplug that cable from your old modem, and plug it into any
yellow port labeled “Wired” on the back of your new Router.
3. Locate the cable that connects your old modem to the ADSL wall
jack. Unplug it from your old modem and then connect it to the
gray port labeled “ADSL line” on the back of your Router.
4. Plug your Router’s power supply into the black port labeled
“Power” on the back of your Router.
5. Wait 20 seconds for the Router to start up. Look at the display on
the front of the Router. Make sure the “Wired” and “Router” icons
are lit in blue. If they are not, recheck your connections.
