Restore on AC Power Loss [Power Off]
When set to [Power Off], the system goes into off state after an AC power loss. When set to
[Power On], the system goes on after an AC power loss. When set to [Last State], the system
goes into either off or on state, whatever the system state was before the AC power loss.
Conguration options: [Power Off] [Power On] [Last State].
Power On By RTC Alarm [Disabled]
Allows you to enable or disable RTC to generate a wake event. When this item is set to
[Enabled], the items RTC Alarm Date / RTC Alarm Hour / RTC Alarm Minute / RTC Alarm
Second will become user-congurable with set values.
Conguration options: [Disabled] [Enabled].
Power On By External Modems [Disabled]
This allows either settings of [Enabled] or [Disabled] for powering up the computer when the
external modem receives a call while the computer is in Soft-off mode. Conguration options:
[Disabled] [Enabled].
The computer cannot receive or transmit data until the computer and applications are fully
running. Thus, connection cannot be made on the rst try. Turning an external modem
off and then back on while the computer is off causes an initialization string that turns the
system power on.
2.6.5 APM Conguration
BIOS SETUP UTILITY
Power
APM Conguration
Restore on AC Power Loss [Power Off]
Power On By RTC Alarm [Disabled]
Power On By External Modems [Disabled] [Disabled]
Power On By PCI Devices [Disabled] [Disabled]
Power On By PCIE Devices [Disabled]
Power On By PS/2 Keyboard [Disabled] PS/2 Keyboard [Disabled]
Power On By PS/2 Mouse [Disabled] PS/2 Mouse [Disabled]
GBE Lan Power [Enabled]
<Enter> to select
whether or not to
restart the system
after AC power loss.
Power On By PCI Devices [Disabled]
Allows you to enable or disable the PME to wake up from S5 by PCI devices. Conguration
options: [Disabled] [Enabled].
Power On By PCIe Devices [Disabled]
Allows you to enable or disable the PCIe devices to generate a wake event. Conguration
options: [Disabled] [Enabled].
