ASUS A7V User’s Manual 15
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) DSW p. 18 DIP Switches
2) JEN p. 18 JumperFree Mode (JumperFree/Jumper Mode)
3) AUDIOCODEC p. 19 Onboard Audio Setting (Enable/Enable)
4) 3VSBSLT p. 19 PCI 3Volt Setting (3 Volt/3 VSB)
5) VIO p. 20 I/O Voltage Setting (3.35 Volt/3.56 Volt/3.69 Volt)
6) DSW 1–5 or 1-4 p. 21 CPU External Frequency Setting
7) DSFID 1–6 p. 22 CPU Core: BUS Frequency Multiple
8) VID1/VID2/VID3/VID4 p. 23 Voltage Regulator Output Setting
Expansion Slots/Sockets
1) System Memory p.24 System Memory Support
2) DIMM1/2/3 p.25 DIMM Memory Module Support
3) Socket 462 (Socket A) p.26 CPU Support
4) PCI1/2/3/4/5 p.27 32-bit PCI Bus Expansion Slots
5) AGP PRO p.29 Accelerated Graphics Port (AGP) Pro
6) AMR p.30 Audio Modem Riser (AMR) Slot
Connectors
1) PS2KBMS p.31 PS/2 Mouse Port Connector (6-pin female)
2) PS2KBMS p.31 PS/2 Keyboard Port Connector (6-pin female)
3) USB p.32 Universal Serial Bus Connectors 0 & 1 (Two 4-pin female)
4) COM1/COM2 p.32 Serial Port Connector (9-pin male)
5) PRINTER p.32 Parallel Port Connector (25-pin female)
6) GAME_AUDIO p.33 Game/MIDI Connector (15-pin female) (optional)
7) GAME_AUDIO p.33 Audio Port Connectors (Three 1/8” female) (optional)
8) FLOPPY p.33 Floppy Disk Drive Port Connector (34 pins)
9) PRIMARY IDE p.34 IDE Connectors (Four 40-1 pins)
SECONDARY IDE
PRIMARY ATA100
SECONDARY ATA100
10) CHASSIS p. 35 Chassis Intrusion Lead (4-1 pins)
11) IR p. 35 Infrared Module Connector (5 pins)
12) WOL_CON p. 36 Wake-On-LAN Connector (3 pins)
13) WOR p. 36 Wake-On-Ring Connector (2 pins)
14) PWR_, CPU_,CHA_FAN p. 37 Chassis, Power Supply, CPU, F_ Fan Connectors (3 pins)
F_FAN
15) CD_IN, AUX, MODEM p. 38 Internal Audio Connectors (4 4-pin) (optional)
Layout Contents
3. H/W SETUP
continued...
