Table A-1. Specifications (continued)
N3302A N3303A N3304A N3305A N3306A
Constant Current Mode
2
Low Range/High Range 3A / 30A 1A / 10A 6A / 60A 6A / 60A 12A / 120A
Regulation 10mA 8mA 10mA 10mA 10mA
Low Range Accuracy 0.1% + 5mA 0.1% + 4mA 0.1% + 7.5mA 0.1% + 7.5mA 0.1% + 15mA
High Range Accuracy 0.1% + 10mA 0.1% + 7.5mA 0.1% + 15mA 0.1% + 15mA 0.1% + 37.5mA
Constant Voltage Mode
2
Low Range/High Range 6V / 60V 24V / 240V 6V / 60V 15V / 150V 6V / 60V
Regulation 5mV 10mV 10mV 10mV 20mV
Low Range Accuracy 0.1% + 3 mV 0.1% + 10mV 0.1% + 3 mV 0.1% + 10mV 0.1% + 3mV
High Range Accuracy 0.1% + 8 mV 0.1% + 40mV 0.1% + 8mV 0.1% + 20mV 0.1% + 8mV
Constant Resistance Mode
2
Range 1 (I >10% of current rating)
Accuracy up to 25% of range
Accuracy >25% to 50% of range
Accuracy >50% to 100% of range
0.067-4 Ω
0.4% ± 24mΩ
0.4% ± 24mΩ
0.8% ± 24mΩ
0.2-48 Ω
1% ± 100mΩ
2% ± 100mΩ
3% ± 100mΩ
0.033-2 Ω
0.4% ±12mΩ
0.4% ±12mΩ
0.4% ±12mΩ
0.033-5 Ω
0.4% ± 24mΩ
0.4% ± 24mΩ
0.8% ± 24mΩ
0.017-1 Ω
0.4% ± 6mΩ
0.4% ± 6mΩ
0.4% ± 6mΩ
Range 2 (I >1% of current rating)
Accuracy up to 25% of range
Accuracy >25% to 50% of range
Accuracy >50% to 100% of range
3.6-40 Ω
1.5% ±80mΩ
2% ±80mΩ
3% ±80mΩ
44-480 Ω
5% ± 500mΩ
10% ± 500mΩ
20% ± 500mΩ
1.8-20 Ω
1.5% ±40mΩ
2% ±40mΩ
3% ±40mΩ
4.5-50 Ω
1.5% ±80mΩ
2% ±80mΩ
3% ±80mΩ
0.9-10 Ω
1.5% ±20mΩ
2% ±20mΩ
3% ±20mΩ
Range 3 (I >0.1% of current rating)
Accuracy up to 25% of range
Accuracy >25% to 50% of range
Accuracy >50% to 100% of range
36-400 Ω
8% ±240mΩ
16% ±240mΩ
32% ±240mΩ
440-4800 Ω
-30/+50%
-40/+133%
-50/+600%
18-200 Ω
6% ±120mΩ
10% ±120mΩ
20% ±120mΩ
45-500 Ω
-10/+25%
-20/+50%
-30/+150%
9-100 Ω
6% ±60mΩ
10% ±60mΩ
20% ±60mΩ
Range 4 (I >0.01% of current rating)
Accuracy up to 25% of range
Accuracy >25% to 50% of range
Accuracy >50% to 80% of range
Accuracy >80% to 100% of range
360-2000 Ω
-25/+100%
-25/+100%
-40/+400%
-40/+400%
4400-12000 Ω
-66/+800%
-66/+800%
-66/+800%
-66/+800%
180-2000 Ω
-20/+66%
-33/+200%
-45/+600%
-50/+2000%
450-2500 Ω
-35/+200%
-45/+500%
-50/+1200%
-50/+2000%
90-1000 Ω
-20/+66%
-33/+200%
-45/+600%
-50/+2000%
Transient Generator
Frequency Range 0.25Hz -10kHz
Frequency Accuracy 0.5%
Duty Cycle Range 3 to 97% (0.25Hz - 1kHz)
6 to 94% (1kHz - 10kHz)
Duty Cycle Accuracy
3
1%
Pulse Width
50µs ± 1% to 4 seconds ± 1%
Current Measurement
2
Low Range / High Range 3A / 30A 1A / 10A 6A / 60A 6A / 60A 12A / 120A
Low Range Accuracy
4
0.05% + 3mA 0.05% + 2.5mA 0.05% + 5mA 0.05% + 5mA 0.05% + 10mA
High Range Accuracy
4
0.05% + 6mA 0.05% + 5mA 0.05% + 10mA 0.05% + 10mA 0.05% + 20mA
Voltage Measurement
2
Low Range / High Range 6V / 60V 24V / 240V 6V / 60V 15V / 150V 6V / 60V
Low Range Accuracy 0.05% + 3mV 0.05% + 10mV 0.05% + 3 mV 0.05% + 8mV 0.05% + 3mV
High Range Accuracy 0.05% + 8mV 0.05% + 20mV 0.05% + 8 mV 0.05% + 16mV 0.05% + 8mV
Power Measurement
2
Accuracy 0.1% + 0.5W 0.1% + 1.2W 0.1% + 0.5W 0.1% + 1.5W 0.1% + 1.2W
2
Specification is +/-(% of reading + fixed offset). Measurement is 1000 samples. Specification may degrade when the unit is subject to an
RF field of 3V/meter, the unit is subject to line spikes of 500V, or an 8kV electrostatic discharge.
3
For example, if the duty cycle setting is 20%, the actual duty cycle would be in the range of 19% to 21%.
4
DC current accuracy specifications apply 30 seconds after input current is applied.
