TRACER 6000 Series Integrated System Manual Section 4 Network Turnup Procedure
612806420L1-1F Copyright © 2005 ADTRAN, Inc. 45
Your Quad T1 module shipment includes the following items:
• Quad T1 module
• Quad T1 module quick start guide
Your Quad Ethernet Switch module shipment includes the following items:
• Quad Ethernet Switch module
• Quad Ethernet Switch module quick start guide
Your Quad E1 module (120Ω interface) shipment includes the following items:
• Quad E1 module
• Quad E1 module quick start guide
Your Quad E1 module (75Ω interface) shipment includes the following items:
• Quad E1 module
• Quad E1 module quick start guide
• DB-25 to DB-25 cable for connecting to the 75Ω BNC breakout panel
Your Octal 75Ω E1 Breakout Panel shipment includes the following items:
•Octal 75Ω E1 Breakout Panel
• 23-inch rack mounting brackets (ADTN P/N 3265622@A)
•Octal 75Ω E1 Breakout Panel quick start guide
Customer Provides
Base System
The following items are necessary to install the TRACER 64x0 system and are not provided:
• 21 to 60 VDC power source with either polarity referenced to ground
• DB-9 cable for VT100 access
• Ethernet cable (for Telnet, SNMP, or TFTP access)
Quad T1 Module
• T1 cables for connecting external equipment to the T1 interfaces (Quad T1 module only)
Quad Ethernet Switch Module
• Ethernet cables for connected external equipment for the switch interfaces (Quad Ethernet Switch
module only)
Quad E1 (120
Ω
)Module
• E1 cables for connecting the Quad E1 module to external E1 devices
Quad E1 (75
Ω
)Module
• BNC cables for connecting the 75Ω E1 Breakout Panel to external devices
