Chapter 6 102
11 Mainboard
12 VGA support
13 CPU support
14 Heatsink module
15 Lower case
16 ODD module
18 HDD module
19 HDD cover
20 Bluetooth bracket
21 Heatsink cover
Item Part Name Item Part Name
1 15.4” w/ CCD LCD cover(Aspire) 13 Conductive tape EP
2 ACER logo(Aspire) 14 LCD cover protect sheet
3 15.4” wide w/ CCD LCD knob 15 LCD CCD cover mylar
4 15.4” wide w/ CCD LCD latch 16 CCD cover protect
5 CCD latch BK-L 17 CCD cover
6 CCD latch BK-R 18 CCD bezel
7 LCD spring 19 CCD LED lens
8 15.4 w/ CCD cover shield 20 CCD name plate assy
9 screw M2.5*3.0-I(BNIXNYLOK)EP 21 CCD hinge
Item Description Item Description
