5
Removing the ExpressCard
Before ejecting the ECR500 ExpressCard from the PC ExpressCard slot,
to click the “Safely Remove Hardware” utility to stop it. “Safely
Remove Hardware” icon is located in the task bar. Click the icon, and
then click the “Safely remove USB Storage Device “ to stop the card.
The reason is to avoid system crashing, data corruption or loss.
Specification
Card Supported:
• Memory Stick Card：8MB ~ 128MB
• Memory Stick PRO 4bit：256MB ~ 4GB
• Secure Digital Card：8MB ~ 1GB
• Multi Media Card：8MB ~ 1GB
• xD-Picture Card
：
8MB ~ 1GB
USB Port
Complies with USB 2.0 High Speed standard
Data Transfer Rate
•Max Speed @ 480 Mbit/s for USB Bulk Transfer
•Memory Stick Card
：
Read 1430 KB/s
、
Write 1202 KB/s
•Memory Stick PRO
：
Read 3809 KB/s
、
Write 2938 KB/s
•Secure Digital Card
：
Read 3141 KB/s
、
Write 1168 KB/s
•Multi Media Card
：
Read 2206 KB/s
、
Write 2080 KB/s
•xD-Picture Card
；
Read 6240 KB/s
、
Write 1211 KB/s
Power Supply
DC3.3V, supplied by ExpressCard’s USB port
EMC Certification
FCC Part 15B,Class B, CE EN55022/EN55024
Operating Systems
Supports Windows 98/98SE and Linux kernel 2.4 and Red Hat
Linux8.0 which all need driver’s installation, and
2000/ME/XP, Mac OS 9.x, OS10.x, which all don’t need
driver’s installation.
Figure7: Safely Remove
