ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
Use only genuine Walker
®
replacement parts. Effective Date 03-31-08
70
ELECTRICAL ASSEMBLY
Electrical Assembly
1 8960-15 Ignition Switch W/Keys 1
(Includes Items # 2, 3 & F349)
2 7854 Plastic Tip, Red 1
3 8960-3 Key Set W/Umbrella 1
4 7941-3 Boot, Circuit Breaker 1
5 7941-6 Circuit Breaker (15 Amp) 1
6 8990-1 Hourmeter (Sendec) 1
7 8996-2 Red Indicator Light Assembly 2
(Includes Items # 8 & 9)
8 8996-4 Red Indicator Lens 2
9 8996-3 Indicator Bulb
*
(Replacement for P/N 8996-2)
10 8536-2 Warning Horn Assembly 1
11 6105-3 Harness Clip 3
12 6942 Relay Switch 30/40 Amp (NC) 3
(Includes Items # 31 & 32)
13 7948-1 Time Delay Module (Less Harness) 1
14 7948-5 Time Delay Harness 1
15 7833-2 Cable Clamp (1 x 1/4) 2
16 2941-5 Safety Switch (NO) 1
17 7203-6 Riser Plate, Seat Switch 1
18 2940-3 Battery Cable (14") 2
19 7910 Battery (12V/340CCA/Dry) 1
20 5975-1 Cable Tie (18# x 3-3/4") 2
21 5932 Battery Terminal Insl., Blk (-) 1
22 5933 Battery Terminal Insl., Red (+) 1
23 5844 Battery Hold-Down Bar 1
24 2910-1 Battery Shield 1
25 5839 Hook Bolt 2
26 7938 Lead Wire, Battery Charge 1
(Alternator to Starter)
27 8941 Circuit Breaker (30 Amp) 1
(Auto Reset/Sealed)
28 5833 Cable Clamp (1/4) 1
29 2940-1 Wire Harness 1
30 5942-4 PTO Safety Switch (NO) 1
31 6941-6 Relay Switch 30/40AMP (NC)
*
32 6941-7 Relay Mount *
Fasteners
F002 10-24 Keps Nut 15
F004 1/4-20 Keps Nut 3
F019 1/4-20 ESNA Wing Nut 2
F025 10-24 x 3/8 PPHMS 3
F026 10-24 x 1/2 PPHMS 10
F031 1/4-20 x 5/8 Hex Bolt 3
F050 1/4 SAE Washer 4
F349 Washer .835 ID 1.122 OD, SS 1
* Service Part Only
