ITEM NUMBER DESCRIPTION PART NUMBER
1 Deck 5074
2 Grass Chute 4261
3 Anti-Scalp Roller AS001
4 5/16-18 x 5 1/2 Gr.5 Bolt NB521
5 5/16-18 Nylok Nut NB181
6 5/16-18 x 8 1/2 Gr.2 Bolt NB136
7 Grass Chute Spring CH5S
8 Idler Assembly 5083
9 Idler Arm 5033
10 3.25" Idler Pulley B527
11 3/8-16 x 2 Gr.2 Bolt NB231
12 3/8-16 2-Way Lock Nut NB280
13 3/8 USS Washer NB271
14 Spacer 5077
15 Idler Spring 682S
16 Spring Hook 2046
17 5/16-18 x 4 Carriage Bolt NB101
18 5/16-18 2-Way Lock Nut NB558
19 3/8-16 x 1 9/16 Gr.2 Shoulder Bolt NB220
ITEM NUMBER DESCRIPTION PART NUMBER
20 3/8-16 x 2 1/2 Gr.5 Bolt NB221
21 Belt Cover 5024
22 3/8-16 Nylok Nut NB182
23 3/8-24 x 1 Gr.5 Bolt NB238
24 3/8-24 2-Way Lock Nut NB216
25 1/4-20 x 1 Gr.5 Bolt NB102
26 1/4-20 Flange Nut NB524
27 Gas Tank Assembly 7569
28 Gas Tank Mount 7520
29 Plastic Gas Tank AS100
30 1/4-20 x 1/2 Gr.5 Bolt NB134
31 1/4 Split Lock Washer NB135
32 Gas Cap 6102NC
33 Elbow Filter AS120
34 Hitch Pin H11
35 15" Tarp Strap BHOLD
36 122" Belt 5058
37 Motor Base 5064
38 5/16-18 x 3/4 Flange Bolt NB596
DECK ASSEMBLY
10
1
4
2
3
5
6
7
8
9
11
12
13
19
18
17
16
1514
33
32
31
30
29
28
27
13
24
23
21
20
37
36
34
35
38
21
22
23
24
13
25
26
22
18
5
5
13
12
FIGURE 2
