The Shop Fox® Deluxe Tool Table must be level before loading any machine or project onto it.
Make sure to measure level along the longest edge of the table and across the shortest edge. Adjust
the leveling feet until the table surface is level. Serious personal injury may occur.
Make certain that any power tool or accessory you mount to your Shop Fox® Deluxe Tool Table is
securely attached before turning it on. A rotating or spinning tool can generate forces which may
cause it to move off the table if not firmly attached. Serious personal injury may occur.
3. Place the table top bottom side up on a work bench or the floor. Lay the leg and brace assembly
upside down on the table top bottom. Move the assembly around until it is evenly spaced on the
surface. Mark the hole locations of the four holes in each corner bracket, and the two holes in
each upper brace.
4. Remove the leg and brace assembly. Use a
1
⁄8'' drill bit in your drill to drill holes at each marked
point to a depth of
3
⁄4". Be careful to not drill all the way through the table top.
5. Slide the frame back onto the table and install all 20 wood screws, first loosely, then tighten when
all are in place.
6. Tighten all the bolts and nuts in the leg and brace assembly.
7. Screw the leveling feet onto the ends of the legs until they are threaded all the way.
8. Move the Tool Table to your desired location.
9. Check to make sure all four (4) table legs are sitting solidly on the floor. Adjust the rubber feet so
the table sits solidly and the table top surface is level.
Adding a Second Shelf
A second shelf can be added to the base, resting on the cross brace supports. This shelf can be cut from
any plywood, solid wood, particle board or MDF material. A minimum thickness of
1
⁄2" is recommended.
The shelf should be cut to dimensions of 16
1
⁄2" x 26
1
⁄2". After finishing the shelf as desired, it can be
installed by removing one of the table legs and inserting the shelf so that it rests upon the top of the
cross supports. Replace the leg. The shelf can be further secured by putting screws through the top edge
of the support into the underside of the shelf. This will provide a convenient surface for further stor-
age.
USING YOUR SHOP FOX
®
DELUXE TOOL TABLE
Mounting Tools On the Table Surface
Tools and accessory equipment can be either temporarily or permanently mounted to the table surface.
If mounting permanently, drill the appropriate size hole through the table surface and secure the tool
with bolts, washers, locknuts and nuts to assure the tool remains permanently secured. If only mounting
temporarily, you may wish to use one of the many varieties of clamping devices to secure the tool.
IF YOU NEED ASSISTANCE
We hope you will find that your Shop Fox® Deluxe Tool Table is easily assembled and put to use. Should
you have any questions about this product, please contact the dealer where you purchased it, or you can
contact the Woodstock International Technical Department at 1-800-840-8420 between the hours of 7:00
am to 5:00 pm PST.
