Please read this instruction manual before assembling the
vacuum cleaner and keep it in the attachment compartment for
reference.
Pay attention to the safety advice.
Your SEBO cylinder vacuum cleaner is designed and made in
Germany to the highest technical standards. Microfilters provide
high filtration. It is efficient and ergonomic. It anticipates the
future and is upgradeable. It follows easily and gives effective
furniture protection.The advanced design of the handle with
built in power control combines comfort with practicality.
Assembling the vacuum cleaner
In the box you will find the machine, the hose with handle, the
telescopic tube and the combination nozzle.
Push the neck (1) of the hose into the suction opening (2) of the
vacuum. It fits only in one position. Fit the combination nozzle
(4) and the handle (6) to the appropriate ends of the telescopic
tube (5). Ensure the locking catches are located in the holes in
the tubes.
Telescopic tube, attachments and combination nozzle
To adjust the telescopic tube (5) use the slide button (7). The cat-
ches (8) release the handle and combination nozzle. The latter
can be adjusted for carpet and hard floor with the pedal (9).
To open the attachment compartment (10) press the button in the
carrying handle recess (11). The attachments fit both the handle
(6) and the telescopic tube (5).
When the machine is horizontal the telescopic tube with combi-
nation nozzle can be parked in the groove (12) at the back of
the machine. When vertical, use the side groove (13).
Technical Data
Motor: 1500 W max Filter bag 5.3 litres
1200 W average Protection Double insulated
Air flow 86 litres /sec Operating
Air Watts 520 range 11 metres
SEBO (UK) Ltd
High Wycome, Bucks HP12 3QL
Tel: (0 14 94) 46 55 33
Fax: (0 14 94) 46 10 44
12
13
2
10
1
11
8
4
9
6
8
7
5
