Operation
FINE-TUNING THE
DETECTOR
After you become familiar with how your de-
tector works, you can fine-tune it to make it
less sensitive to interference and more se-
lective in what it finds.
Adjusting Sensitivity
To adjust the search coil’s ability to detect
objects at different depths in the soil, rotate
SENSITIVITY
between
MIN
and
MAX
. For
maximum detection depth, leave
SENSITIVI-
TY
set as high as possible. If the detector
makes a “chattering” noise, decrease
SENSI-
TIVITY
until the chatter stops.
Adjusting Ground
Setting
GROUND
takes a little time, but is crit-
ical for accurate operation.
GROUND
tunes
out false signals from mineralized soil. Fol-
low these steps to set
GROUND
.
1. Set
MODE
to
VLF
and lower the search
coil to
1
/
2
to 2 inches above the ground.
2. If the pointer swings to the right (Non-
ferrous), turn
GROUND
to
NORMAL
. If
the pointer swings to left (Ferrous), turn
GROUND
to
BASALT
.
3. Raise the search coil about 1 foot from
the ground and press the red button on
the handle. The pointer returns to the
center.
4. Repeat Steps 1–3 until the pointer stays
close to the center each time you lower
the search coil to the ground.
After you set
GROUND
, the detector is set for
the soil type at that particular site. Do not re-
set it until you use the detector at a different
site.
Adjusting Discrimination
Discrimination is the detector’s ability to dif-
ferentiate between types of metal. The de-
tector’s
DISCRIMINATION
setting determines
whether the detector will distinguish between
different types of ferrous and non-ferrous
metals.
If
MODE
is set to
TR2
, start with
DISCRIMINA-
TION
set to mid-range. While you use the de-
tector, adjust
DISCRIMINATION
to the best
position. As you set
DISCRIMINATION
higher,
the detector becomes more sensitive to the
differences between large aluminum and
gold pieces, for example, but some small
valuable pieces, such as coins and small
rings, might be overlooked.
As you set
DISCRIMINATION
to higher levels,
the detector first does not detect small piec-
es of silver paper, then thick foil, and finally
metal objects like pull tabs from aluminum
cans.
Note:
Each time you use the detector in a
different area, you must readjust
DISCRIMI-
NATION
. Each search location presents new
challenges.
FALSE SIGNALS
Because your detector is extremely sensi-
tive, trash-induced signals and other sources
of interference might cause signals that
seem confusing. The key to handling these
types of signals is to dig for only those tar-
gets that emit a strong, repeatable signal. As
you sweep the search coil back and forth
over the ground, learn to recognize the differ-
ence between signals that occur at random
and signals are stable and repeatable.
To reduce false signals when searching ar-
eas containing large amounts of trash, scan
only a small area at a time using slow, short
overlapping sweeps.
