ItemDescriptionQty.
A.*Bolt, 1/4-20X8”2
B.*Washer 1/42
C.Hold Down bar (PN 0036525.02)1
D.*Nyloc nut, 1/4-202
E.*Spacer (optional)2
*All parts are standard parts at your local hardware store.
CAUTION: This battery charging system is intended to
recharge weak batteries, not to “boost start” vehicles.
Battery Installation
Coleman Powermate recommends a 12 v battery with at
least 235 cranking amps. Model U1L, Lawn and Garden
Battery. Place the battery in the position provided. Then place
the bolts through the loops on the Hold-Down bracket. Place
the assembly over the battery and place the bolts through the
holes on the battery pan and tighten down the Hold-Down
assembly with the 1/4-20 nuts provided.
Spacers may be added depending on the battery height.
WARNING: Batteries contain sulfuric acid
(when filled). May contain explosive gasses.
Always abide by safety warnings provided
with the battery.
-Keep sparks, flame and cigarettes away.
-Hydrogen gas is generated during charging
and discharging.
-Always shield eyes, protect skin and clothing
when working near batteries.
Connect the red 8 ga. battery lead to the positive battery
post and the black 8 ga. battery lead to the negative battery
post with the bolts and nuts provided.
Warranty Coverage: Powermate Corporation (the Company)
warrants to the original retail customer in North America that it
will repair or replace, free of charge, any parts found by the
Company or its authorized service representative to be
defective in material or workmanship. This warranty covers the
cost of replacement parts and labor for defects in material or
workmanship.
Not Covered:
· Transportation charges for sending the product to the
Company or its authorized service representative for
warranty service, or for shipping repaired or replacement
products back to the customer; these charges must be
borne by the customer.
·
Engine is covered exclusively by a separate warranty from
the engine manufacturer, included with the engine Manual.
· Damages caused by abuse or accident, and the effects of
corrosion, erosion and normal wear and tear.
· Warranty is voided if the customer fails to install, maintain
and operate the product in accordance with the instructions
and recommendations of the Company set forth in the
owner's manual, or if the product is used as rental
equipment.
·
The Company will not pay for repairs or adjustments to the
product, or for any costs or labor, performed without the
Company's prior authorization.
Warranty Period: Two (2) years from the date of purchase on
products used solely for consumer applications; if a product is
used for business or commercial applications, the warranty
period will be limited to one (1) year from the date of purchase.
For warranty service, the customer must provide dated proof of
purchase and must notify the Company within the warranty
period.
For warranty service: Call toll free 800-445-1805, or write
to Powermate Corporation, Product Services, 4970 Airport
Road, P. O. Box 6001, Kearney, NE 68848.
EXCLUSIONS AND LIMITATIONS: THE COMPANY MAKES
NO OTHER WARRANTY OF ANY KIND, EXPRESS OR
IMPLIED. IMPLIED WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY AND OF FITNESS
FOR A PARTICULAR PURPOSE, ARE HEREBY
DISCLAIMED. THE WARRANTY SERVICE DESCRIBED
ABOVE IS THE EXCLUSIVE REMEDY UNDER THIS
WARRANTY; LIABILITY FOR INCIDENTAL AND
CONSEQUENTIAL DAMAGES IS EXCLUDED TO THE
EXTENT PERMITTED BY LAW.
This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state. Some states
do not allow a disclaimer of implied warranties, or the exclusion
or limitation of incidental and consequential damages, so the
above disclaimers and exclusions may not apply to you.
3
English
BATTERY KIT PARTS LIST
BATTERY INSTALLATION
LIMITED WARRANTY
