Porter-Cable PCH2600C Pressure Washer User Manual



20- ENG
D25804
CALL 1-888-559-8550
TO FIND A LOCAL AUTHORIZED SERVICE CENTER NEAR YOU FOR
REPAIRS
AND SERVICE PART PURCHASES.
ALWAYS REFER TO THE MANUALS SUPPLIED WITH THIS UNIT
QUICK FACTS
Use fresh high quality gas.
Add stabilizer to fuel tank and run engine for 5 minutes before storage.
Pump oil: Refer to owners manual supplied with this unit.
Engine oil: Refer to engine manual supplied with this unit.
Some units are equipped with a low oil sensor and adequate oil must be
added or the unit will not start.
Use only cold water.
Don't operate unit with clogged or missing water filter/screen.
Don't operate unit without adequate water supply to pump. Adequate
water supply is a minimum of 20 psi and 5 gpm.
The pressure setting is preset at the factory to achieve optimum cleaning.
If you need to lower the pressure setting, refer to the owners manual for
proper procedure.
Pull gun trigger every 2 minutes while engine is running.
Don't allow water to freeze in pump.
Siphon RV antifreeze into pump for cold weather storage or long term
storage.
Pump is equipped with a thermal relief valve. If the water overheats, this
valve will open and allow a gush of water to escape. Once the water is
released, the valve closes allowing the pump to operate normally.
Don't allow hoses to contact the HOT engine muffler during or after use.
Never pull the hose to move the unit.
Do not adjust or attempt maintenance without consulting engine manual
or an authorized engine service center.
Add stabilizer to fuel tank and run engine for 5 minutes before storage.
Always turn on the water before starting the engine.
Use only soaps and chemicals designed for pressure washer use.
Keep nozzle unclogged. Refer to manual for cleaning procedures.
Chemical/soap cannot be siphoned in high pressure setting. Only in low
setting.
Follow recommended maintenance schedule for engine & pump. Refer to
manuals.
Draw clean water through chemical inlet.
Add stabilizer to fuel tank and run engine for 5 minutes before storage.
Don't allow water to freeze in pump, gun, wand or hoses.
Siphon RV antifreeze into pump for cold weather storage or long term
storage.
GAS
OIL
WATER
PRESSURE
ADJUSTMENT
PUMP
BY
-PASS MODE
THERMAL
RELIEF VALVE
HOSE
ENGINE
SOAP
/CHEMICALS
NOZZLE
MAINTENANCE
SCHEDULE
STORAGE OR
WINTERIZING
Never leave unit running for more than 2 minutes without pulling gun
trigger; doing so may damage pump and void warranty.
