16
Flying objects.
Make sure nozzle is secure before squeezing trigger. If nozzle is not secure it will become a
projectile. Serious injury can occur.
WARNING
pump
hose
spray gun
Operation Instructions
Installing Nozzles
To install a nozzle pull back the collar and push the nozzle into the coupler. Once the connection is
made, pull on the nozzle to make sure it is secure.
Attach Quick Connect Couplers
-To install the hose onto the pump, pull back the collar and push the hose into the coupler on the
pump. Then push the collar completely out.
-To install the hose onto the spray gun, pull back the collar on the spray gun and push the hose into
the coupler on the spray gun. Then push the collar completely out.
Once the connections are made, pull on the hose to make sure it is secure.
CORRECT INCORRECT
nozzle
colla
r
cou
p
le
r
lance
collar completely
pushed out.
collar NOT completely
pushed out.
