North Star M157305H Pressure Washer User Manual



7
II.) Assembly Instructions
A. 1. Carefully raise the pressure washer off the floor by
using blocks or ramps. Make sure the pressure
washer is secure before proceeding.
2. Install the two wheels as shown with grease zerk
away from frame.
3. Slide the two wheel retainers onto the end of the
axle. Tighten the set-screw with a hex wrench.
Description Qty.
Wheel 2
Wheel Retainer 2
B. 1. Install the pressure hose onto the pressure washer
as shown.
2. Connect the other end of the pressure hose to the
spray gun as shown.
3. Make sure all plumbing connections are tight.
Description Qty.
Spray Gun/ Lance 1
Spray Hose 1
Wheel Retaine
r
Wheel
A
xle
Grease Zerk
