RevisionCommentsPart DescriptionPart No.Ref.
Drawing Image Numberdwg15342
CYL 2.5X8X1.12 ROD (TIE)1 PIN810-200c1.
PIN CLEVIS 1 X 2 3/4 USABLE LG805-004C2.
TOOLBAR PIVOT PIN315-737D3.
Rev. 2 not compat. w/Rev. 1(S/N 259230+)HHCS 5/16-18X2 GR5802-115C4.
Rev. 1(S/N 259229-)HHCS 1/4-20X2 GR5802-152C4.
Rev. 2 not compat. w/Rev. 1(S/N 259230+)NUT LOCK 5/16-18 PLT803-011C5.
Rev. 1(S/N 259229-)NUT LOCK 1/4-20 PLT803-007C5.
REAR DECK CYL LUG PIN315-487D6.
4522 CEN. DECK CYL. LUG315-309H7.
PIN CLEVIS 1 X 4 3/4 USABLE805-131C8.
FLIP LATCH WLDMNT RH315-186H9.
Rev. 2WASHER FLAT 1 SAE804-029C10.
Rev 1; Use up stockWASHER FLAT 1 USS804-028C10.
Rev. 2(S/N 508304+)PIN COTTER 5/32 X 1 1/4 LG805-045C11.
Rev 1; Use up stock(S/N 508303-)PIN COTTER 3/16 X 1 3/4 PLT805-017C11.
PIVOT STOP SPRING807-026C12.
GREASE ZERK 1/4-28 THD FORMING800-080C13.
4522 REAR DECK TRANS. PIVOT315-303H14.
PIN COTTER 3/16 X 1 3/4 PLT805-017C15.
Replaces Hair Pin CotterPIN COTTER 3/16 X 1 3/4 PLT805-017C16.
05/21/08 AFM4522 All-Flex Mower 315-360P 7
Table of Contents Part Number Index
Section 2: Frame Land Pride
Center Deck Pivot
Applies to AFM4522
