The tongue is equipped with a screw pin shackle clevis to provide movement in all directions on
rough uneven ground. To prev ration or debris, place the screw
pin through the tow vehicle hitch and clevis and turn the screw pin until snug.
The tongue is designed to adjust from left to right within the hitch pivot. This allows the mowers
position to be varied behind the tow vehicle. This is accomplished by pulling the 5/16” wire lock
pins out and choosing two other hole locations on the tongue. See Figure 3.
Figure 5: Adjusting Rough Cut Mower Cutting Height
ent loss of the screw pin due to vib
OffsDirectly Behind et
Figure 4: Rough Cut Tow Behind Towing Suggestions
B. ADJUSTING CUTTING HEIGHT
W
be
ARNING: Shut off the engine and allow the mower blades to come to a complete stop
fore adjusting the cutting height.
Adjustment Crank: Roughly 6
turns e
Mower
Blade
Lower Edge of
Deck
Measure
and Add 1
This Distance
-5/16” to get
Cutting Height
1-5/16”
Cutting Height
Smooth
Surface
q
uals 1.0”
7
