HD200 and HD300 Sprayers
Machine
Tank High-density, polyethylene tank with quick-fi ll attaching point; anti-siphoning, low center of gravity
Frame Welded steel
Rate capacity HD200: 200 U.S. gal. (757 L)/HD300: 300 U.S. gal. (1135.6 L)
Agitation Jet agitation adjusted by proportional control valve,
5
/
16
-in. orifi ce
Pressure/fl ow regulator Electric
Filter 100-mesh; self-cleaning
Boom shutoff valves Electric
Throttling valves Standard; adjustable
Optional Centrifugal Pump
Construction Cast iron or stainless steel
Seal type Life Guard™ silicone-carbide
PTO Hydraulically driven motor powered by ProGator auxiliary hydraulic pump
Max. fl ow 97 U.S. gal. per minute (367 L/min)
Max. pressure 95 psi (6.6 bar)
Optional Diaphragm Pump
Number of diaphragms 3
Lubrication Oil
PTO Hydraulically driven motor powered by ProGator auxiliary hydraulic pump
Max. fl ow 30.1 U.S. gal. per minute (113.9 L/min)
Max. pressure 290 psi (20 bar)
Relief pressure 290 psi (20 bar); adjustable
Manual Controller
Type Weather-resistant control box with electronic control switches and liquid pressure gauge; removable without tools for storage
Switches on control box Individual Boom On/Off, Boom Master, Foam Marker, Boom Lift/Lower, Pressure Increase/Decrease
Liquid gauges 100 psi (6.9 bar) gauge for centrifugal pumps; 300 psi (20.7 bar) for diaphragm pumps
Automatic Rate Controller
Type Weather-resistant control box with electronic control switches and digital pressure display; removable without tools for storage
Switches on control box Individual Boom On/Off, Boom Master, Foam Marker, Boom Lift/Lower, Pressure Increase/Decrease, Auto/Manual
Pressure sensor 0–363 psi (0–25 bar)
Gauges Digital speed, digital pressure, digital tank sight gauge, and digital fl ow rate on rate controller screen
Rate control Constant pressure or constant fl ow can be selected
Specifications
FLEXIBILITY NO DEDICATED
SPRAYER CAN MATCH
Once you’re fi nished spraying, it’s truly simple to
detach the tank and free your ProGator for other
tasks. Just remove three mounting pins, disconnect
hydraulic lines and electrical connectors, attach stor-
age stands—and you’re done. You don’t even have to
use any tools. Plus, stands include caster wheels so
it’s easy to move sprayer around, and re-install.
