Lift Capacities
(continued)
450D LC
Boldface italic
type indicates hydraulic-limited capacities; lightface type indicates stability-limited capacities, in lb. (kg). Ratings at bucket lift hook; machine equipped with
20,172-lb. (9150 kg) counterweight; standard gauge; and situated on firm, uniform supporting surface. Total load includes weight of cables, hook, etc. Figures do not exceed
87 percent of hydraulic capacities or 75 percent of weight needed to tip machine. All lift capacities are based on SAE J1097.
Load Point 10 ft. (3.05 m) 15 ft. (4.57 m) 20 ft. (6.10 m) 25 ft. (7.62 m) 30 ft. (9.15 m)
Height Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side
With 23-ft. 0-in. (7.0 m) boom; 11-ft. 2-in. (3.4 m) arm; 2.7-cu.-yd. (2.1 m
3
), 3,593-lb. (1630 kg) bucket; and 36-in. (900 mm) triple semi-grouser shoes
20 ft. (6.10 m)
21,500 (9752) 21,500 (9752) 18,500 (8392)
16,100 (7303)
15 ft. (4.57 m)
28,000 (12 701) 28,000 (12 701) 23,700 (10 750)
21,700 (9843)
21,300 (9662)
15,800 (7167)
10 ft. (3.05 m)
33,400 (15 150)
29,400 (13 336)
26,500 (12 020)
20,700 (9389)
22,700 (10 297)
15,200 (6895)
5 ft. (1.52 m)
37,900 (17 191)
27,600 (12 519)
29,200 (13 245)
19,700 (8936)
24,100 (10 932)
14,700 (6668)
Ground Line
25,400 (11 521) 25,400 (11 521) 40,200 (18 235)
26,500 (12 020)
30,800 (13 971)
18,900 (8573) 24,100 (10 932) 14,200 (6441)
–5 ft. (–1.52 m)
43,200 (19 595)
41,300 (18 734)
40,100 (18 189)
26,000 (11 794)
31,100 (14 107)
18,500 (8392) 23,800 (10 796) 13,900 (6305)
–10 ft. (–3.05 m)
38,800 (17 600) 38,800 (17 600) 48,200 (21 863)
41,600 (18 870)
37,700 (17 101)
26,000 (11 794)
29,600 (13 426)
18,400 (8346)
23,100 (10 478)
14,000 (6350)
–15 ft. (–4.57 m)
49,300 (22 362) 49,300 (22 362) 41,100 (18 643) 41,100 (18 643) 32,800 (14 878)
26,400 (11 975)
25,500 (11 567)
18,700 (8482)
–20 ft. (–6.10 m)
29,600 (13 426)29,600 (13 426) 23,400 (10 614) 23,400 (10 614)
With 23-ft. 0-in. (7.0 m) boom; 12-ft. 10-in. (3.9 m) arm; 2.5-cu.-yd. (1.9 m
3
), 5,434-lb. (1570 kg) bucket; and 36-in. (900 mm) triple semi-grouser shoes
25 ft. (7.62 m)
11,200 (5080) 11,200 (5080)
20 ft. (6.10 m)
17,900 (8119)
16,200 (7348)
15 ft. (4.57 m)
22,100 (10 024)
21,900 (9934)
20,000 (9072)
15,800 (7167)
10 ft. (3.05 m)
43,900 (19 913) 43,900 (19 913) 31,100 (14 107)
29,700 (13 472)
25,000 (11 340)
20,700 (9389)
21,500 (9752)
15,200 (6895)
5 ft. (1.52 m)
35,100 (15 921) 35,100 (15 921) 36,100 (16 375)
27,700 (12 565)
27,900 (12 655)
19,600 (8891)
23,100 (10 478)
14,500 (6577)
Ground Line
32,500 (14 742) 32,500 (14 742) 39,200 (17 781)
26,300 (11 930)
29,900 (13 563)
18,700 (8482) 23,900 (10 840) 14,000 (6350)
–5 ft. (–1.52 m)
19,400 (8800) 19,400 (8800) 44,000 (19 958)
40,500 (18 371)
39,800 (18 053)
25,600 (11 612)
30,700 (13 925)
18,200 (8255) 23,500 (10 660) 13,600 (6169)
–10 ft. (–3.05 m)
36,700 (16 647) 36,700 (16 647) 50,200 (22 770)
40,700 (18 461)
38,300 (17 373)
25,500 (11 567)
29,800 (13 517)
18,000 (8165) 23,400 (10 614) 13,500 (6124)
–15 ft. (–4.57 m)
56,100 (25 447) 56,100 (25 447) 43,900 (19 913)
41,400 (18 779)
34,300 (15 558)
25,800 (11 703)
26,800 (12 156)
18,200 (8255)
–20 ft. (–6.10 m)
33,900 (15 377) 33,900 (15 377) 26,800 (12 156)
26,500 (12 020)
19,200 (8709)
18,900 (8573)
With 23-ft. 0-in. (7.0 m) boom; 16-ft. 1-in. (4.9 m) arm; 1.8-cu.-yd. (1.4 m
3
), 2,579-lb. (1170 kg) bucket; and 36-in. (900 mm) triple semi-grouser shoes
15 ft. (4.57 m)
18,800 (8528)
17,600 (7983)
10 ft. (3.05 m)
23,600 (10 705)
22,700 (10 297)
20,900 (9480)
16,900 (7666)
5 ft. (1.52 m)
48,100 (21 818)
46,600 (21 138)
34,000 (15 422)
30,100 (13 653)
27,000 (12 247)
21,500 (9752)
22,900 (10 387)
16,100 (7303)
Ground Line
42,900 (19 459) 42,900 (19 459)38,600 (17 509)
28,400 (12 882)
29,900 (13 563)
20,400 (9253)
24,700 (11 204)
15,500 (7031)
–5 ft. (–1.52 m)
19,100 (8664) 19,100 (8664) 43,400 (19 686)
42,200 (19 142)
40,900 (18 552)
27,200 (12 338)
31,700 (14 379)
19,600 (8891) 24,800 (11 249) 15,000 (6804)
–10 ft. (–3.05 m)
30,000 (13 608) 30,000 (13 608) 53,900 (24 449)
41,800 (18 960)
41,100 (18 643)
26,700 (12 111)
32,000 (14 515)
19,200 (8709) 24,500 (11 113) 14,700 (6668)
–15 ft. (–4.57 m)
43,500 (19 731) 43,500 (19 731) 51,200 (23 224)
42,000 (19 051)
38,900 (17 645)
26,700 (12 111)
30,600 (13 880)
19,100 (8664)
24,300 (11 022)
14,700 (6668)
–20 ft. (–6.10 m)
58,800 (26 672) 58,800 (26 672) 44,000 (19 958)
42,800 (19 414)
34,100 (15 468)
27,100 (12 292)
26,600 (12 066)
19,400 (8800)
19,500 (8845)
15,100 (6849)
–25 ft. (–7.62 m)
31,900 (14 470) 31,900 (14 470) 24,700 (11 204) 24,700 (11 204)
With 20-ft. 8-in. (6.3 m) ME boom; 9-ft. 6-in. (2.9 m) ME arm; 3.3-cu.-yd. (2.5 m
3
), 4,123-lb. (1870 kg) bucket; and 36-in. (900 mm) triple semi-grouser shoes
20 ft. (6.10 m)
25,400 (11 521) 25,400 (11 521) 22,500 (10 206)
21,700 (9843)
15 ft. (4.57 m)
36,200 (16 420) 36,200 (16 420) 28,900 (13 109)28,900 (13 109) 25,100 (11 385)
21,100 (9571)
10 ft. (3.05 m)
33,700 (15 286)
29,100 (13 200)
27,300 (12 383)
20,200 (9163)
17,700 (8029)
14,600 (6623)
5 ft. (1.52 m)
37,900 (17 191)
27,400 (12 429)
29,500 (13 381)
19,200 (8709)
22,700 (10 297)
14,100 (6396)
Ground Line
55,100 (24 993)
41,200 (18 688)
39,900 (18 099)
26,200 (11 884)
30,700 (13 925)
18,600 (8437)
20,000 (9072)
13,800 (6260)
–5 ft. (–1.52 m)
51,800 (23 496)
41,200 (18 688)
39,200 (17 781)
25,800 (11 703)
30,200 (13 699)
18,200 (8255)
–10 ft. (–3.05 m)
45,600 (20 684)
41,700 (18 915)
35,400 (16 057)
26,000 (11 794)
26,800 (12 156)
18,400 (8346)
–15 ft. (–4.57 m)
35,000 (15 876) 35,000 (15 876) 27,000 (12 247)
26,700 (12 111)
4 ft. 6 in. (1.36 m)
with
eed
Side
(6804)
(6577)
(6350)
(6169)
(6078)
