iOptron 8504 Telescope User Manual



16
Goto Landmark:
Use or button to move the cursor to
“Goto Landmark” line, press ENTER. The
first saved landmark will display:
Use or button to move the cursor and
or button to change the number, then
press ENTER. The mount will automatically
slew to the target.
This function only works if a land object has
been stored in database.
Record New Landmark
Use or button to move the cursor to
“Record New Landmark” line, and press
ENTER. A landmark screen will show:
Use and keys to slew the
telescope to the target you want to observe.
Press SPEED button to change the slew
speed if needed. Then press ENTER to
save the target. Enter the Name using or
to select form A-Z, 0-9 and “-, space“.
(such as Z0). The object No. will be
assigned by the system in order. Press
ENTER to record your landmark.
Add a new Landmark
Use or button to move the cursor to
“Add a new Landmark” line, and press
ENTER. Enter the Name using or to
select form A-Z, 0-9 and “-, space“. (such as
Z0). A coordinate setting screen will show:
Use or button to move the cursor, and
or button to change the number. Then
press ENTER. Press ENTER to add the
landmark infomation.
Edit One Data
Use or button to move the cursor to
“Edit One Data” line, and press ENTER.
The first saved landmark will display:
Use or button to move the cursor and
or button to change the number, then
press ENTER. You can change the name
and Alt/Azi coordinates accordingly.
Delete One Data
Use or button to move the cursor to
“Delete One Data” line, and press ENTER.
The first saved landmark will display:
Use or button to move the cursor and
or button to change the number, then
press ENTER. Press ENTER to confirm the
deletion.
No: 01
Name: Z0
A 23º33.1’ Z225º58.8’
No: 01
Name: Z0
A 23º33.1’ Z225º58.8’
No: 01
Name: Z0
A 23º33.1’ Z225º58.8’
Add a New landmark
Edit One Data
Delete One Data
Delete All
Enter Alt. Azi.
Alt: 13º 0.0’
Azi: 25º58.8’
A 13º 0.0’ Z 25º58.8’
Use arrow keys to
Move. Press “ENTER”
To modify. 2X
