Page 3For technical questions, please call 1-800-444-3353.SKU 95343
UNPACKING
When unpacking, check to make sure that the
item is intact and undamaged. If any parts are missing
or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as
possible.
ATTACHING AND REMOVING
THE BIT
Insert the Shaft into a vise. Grasp the Bit with a 1.
wrench and unscrew the Bit.
Thread on the new Bit or ip to unused cutter 2.
side.
Remove Shaft and Bit from vise.3.
OPERATION INSTRUCTIONS
The Spot Weld Cutter is now ready to be 1.
mounted to the drill. Read the drill owner’s
manual for instructions on properly mounting drill
bits.
Before using the Spot Weld Cutter, make certain 2.
that the work piece is rmly clamped and secured
in place. Place the Spot Weld Cutter Bit over
the spot weld and slowly begin drilling into the
work piece. Always hold the drill rmly with both
hands to ensure safe operation of the Spot Weld
Cutter. Note: If Bit does not stay in spot weld
depression, dimple the center of the weld with a
punch (not included).
Drill until the spot weld is removed. Do not over 3.
drill.
Note: When working on a vehicle, be certain to protect
all electrical components from damage.
Follow the vehicle owner’s manual for securing
electrical systems. Make certain that the drilling
path is clear of all cables, wires and electrical
components.
Disconnect and isolate the negative battery a.
cable and disarm the passive restraint
system.
Protect computer modules, connectors, and b.
wiring from dirt, heat, moisture and metal chips.
INSPECTION, MAINTENANCE,
AND CLEANING
1. WARNING! Make sure the Power Switch
of the drill is in its “OFF” position and that the
tool is unplugged from its electrical outlet before
performing any inspection, maintenance, or
cleaning procedures.
BEFORE EACH USE,2. inspect the general
condition of the tool. Check for loose or broken
parts and any other condition that may affect its
safe operation. If abnormal noise or vibration
occurs, have the problem corrected before
further use. Do not use damaged equipment.
Clean the Spot Weld Cutter after each use. 3.
Remove any debris, grease, oil and dirt. Store in
the Blow Mold Case in a secure place out of the
reach of children.
