SKU 94837 For technical questions, please call 1-800-444-3353
Specifications
Save This Manual
You will need the manual for the safety warnings and precautions, assembly instructions,
operating and maintenance procedures, parts list and diagram. Keep your invoice with this
manual. Write the invoice number on the inside of the front cover. Keep the manual and
invoice in a safe and dry place for future reference.
Safety Warnings and Precautions
WARNING: When using tool, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this tool!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet
locations. Don’t expose to rain. Keep work area well lighted. Do not use electrically
powered tools in the presence of flammable gases or liquids.
3. Keep children away. Children must never be allowed in the work area. Do not let
them handle machines, tools, or extension cords.
4. Store idle equipment. When not in use, tools must be stored in a dry location to
inhibit rust. Always lock up tools and keep out of reach of children.
5. Dress properly. Do not wear loose clothing or jewelry as they can be caught in
moving parts. Protective, electrically non-conductive clothes and non-skid footwear
are recommended when working. Wear restrictive hair covering to contain long hair.
REV 07a; 09h
Item Description
Pump Output 4.3 GPM (16.56 liter per min.) @ 3,60 RPM
Pump Type Two Stage
Hydraulic Capacity 8 Tons, single stage pump
Ram Travel 19-7/8 inches
Ram Diameter 1.78 inches
Cutting Wedge Thickness: 13/16 incl; Thick cabon steel
Log Capacity 20” (long) x 8” (dia.)
Towing For off-road use only (not DOT approved); Hitch size: 1-7/8 inches
Hydraulic Fluid Reservoir 1.5 gallons
Type of Hydraulic Fluid 10W AW Hydraulic Fluid or Dexron III automatic transmission uid.
Change every 100 hours of use.
Wheel Size Wheel: 15 inch diameter; Hub: 8-1/2 inches; Wheel base: 20 inches
Tire Pressure 60 PSI Maximum
Engine Briggs & Stratton Model 9J902 gasoline engine
Oil: 18 oz. of SAE 30 detergent oil rated SF,
SG, SH or higher; Spark Plug gap: 0.030”
(0.76mm), Part #802592; Gas type: unleaded,
85 octane or higher
Overall Dimensions 68”(L) x 27-3/4”(W) x 31-3/4”(H)
Weight 250 lbs.
