PRODUCT SPECIFICATIONS
Item Description
Electric Motor 2 HP, 110 V, 60 Hz, Single Phase, 1150 Watts
Power Cord 14 AWG x 3C, Double Insulated
Measured Amperage 8.1 with no load
10 with load
30 at start-up
Maximum Force 4 Tons (8,000 Lbs.)
Log Size Capacity 20” L x 10” D
Wedge Size 5”
Ram Travel 14-1/2”
Ram Diameter 1.75”
Hydraulic Oil Capacity 3.2 Quarts
Overall Dimensions 30-1/2” L x 12” W x 19-1/4” H
Weight 97 Lbs.
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the
front cover. Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered and dark areas invite
accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a splitter tool.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.
SKU 93815 PAGE 2
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
