29
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 31104488 Upper handle assy. 1
2 33305469-3 Bail switch 1
3 31110487 Motor engagement box 1
4 33309470-2 Lower handle 1
5 31102467-2 Cam lock assy. 4
6 34106467-1 Handle knob 2
7 3411135 Cord guide 1
8 34103488 Battery housing 1
9 34102488 Battery door 1
10 33905470 Spring 1
11 31104975 40V 146Wh Battery 1
12 32201110 Screw 2
13 333012470 Height adjustment plate 1
14 34202470 Dust plate 1
15 32204100 Self-lock nut M5 2
16 36501470 Cover of connector assy. 2
17 34107470 Key holder 1
18 31201470 Key 1
19 33904470 Spring 1
20 33203470 Pin 1
21 36901487 Diode 1
22 34101488 Motor cover 1
23 3331035 Rectier heat radiator 1
24 36101470 Motor 1
25 34105470-2 Cam lock cover 2
26 34106470-2 Cam lock base 2
27 31106250-1 Motor switch cover 1
28 34101470-2 Deck 1
29 34106488 Wheel cover 4
30 3290506 Washer 2
31 31102488 6” wheel 2
32 33301470 Front wheel axle 1
33 33307470 Clip 4
34 3320238 Spindle bushing 1
35 34117470 Blade holder 1
36 33303488 16” blade 1
37 3410535 Blade insulator 1
38 3331435 Spacer 1
39 3221037 Nut M10X1.25 1
40 3290135 Pin 6
41 3290650 C-clip 3
