1 0F9529 1 WELDMENT RADIATOR SUPPORT 2.4L
2 0F2608 1 RADIATOR 598 X 568 X 49 CPL RH
3 0F5263 1 V-BELT 31/64" X 57-3/8"
4046526 5WASHER LOCK M10
5 059981 4 SCREW HHC M10-1.5 X 30 G10.9
6 022222 2 SCREW HHC 5/16-24 X 1-1/2 G5
7 0F5050 1 SHIELD RADIATOR C5
8 042568 8 SCREW HHC M6-1.0 X 20 G8.8
9 0F2573 1 PULLEY FAN V-GROOVE 9"
10 0F4011 1 FAN COOL 22" DIA 10 BLADE LH
11 0F2572 1 ARM TENSIONER
12 0F5689 1 SCREW SHC SHLDR LKG M8X16LG
13 0F2862 1 SPRING TENSION CPL
14 0F2560 1 PULLEY V-BELT 4" FLANGED
15 022131 7 WASHER FLAT 3/8-M10 ZINC
16 0E2507 1 PROBE COOLANT LEVEL 3/8NPTF
17 035685 4 CLAMP HOSE #28 1.32-2.25
18 0F2561 1 HUB FLEX PLATE
19 0C8145 8 WASHER FLEX (THIN)
20 052250 2 TAPE FOAM 1 X 1 (26.75” LG)
21 0C7043 12 DISK FLEX
22 043790 1 BARBED EL 90 3/8 NPT X 3/8
23 022473 16 WASHER FLAT 1/4-M6 ZINC
24 0C8146 2 SCREW HHC 5/16-24 X 1.124
25 022097 16 WASHER LOCK M6-1/4
26 076749 1 TANK COOLANT RECOVERY
27 048031C 1 CLAMP HOSE BAND 1/4
28 031971 1 BEARING #6205 2NSE C3 E SRI2 S
29 0F4496 1 PULLEY 4.5" DIA MACHINED
30 042911 1 SCREW HHC M10-1.5 X 30 G8.8
31 0F2872 1 SCREW HHC 1/2-13 X 2" G8
32 022304 2 WASHER FLAT 1/2 ZINC
33 022195 1 WASHER LOCK 1/2
34 022196 1 NUT HEX 1/2-13 STEEL
35 0F8651 9 SCREW HHFC M8-1.25 X 20 W/M6
36 045772 1 NUT HEX M10-1.5 G8 YEL CHR
37 0F9867 1 SHAFT FAN DRIVE
38 0F2461 1 RETAINER BEARING
39 022145 1 WASHER FLAT 5/16-M8 ZINC
40 022129 10 WASHER LOCK M8-5/16
41 039414 1 SCREW HHC M8-1.25 X 35 G8.8
42 082774 1 KEY WOODRUFF 4 X 19D
43 0F9982 1 HOSE LOWER RADIATOR
44 0F9781 1 HOSE UPPER RADIATOR 2.4L HYUND
45 049813 8 NUT HEX M6 X 1.0 G8 YEL CHR
46 052644 1 SPACER .5 X 1.5 X .25 STL/ZINC
47 0C8566 8 SCREW HHFC M6-1.0 X 20 G8.8
48 0C2454 2 SCREW THF M6-1 X 16 N WA Z/JS
49 090283 1 CAP RADIATOR 13 PSI
50 080713 1 BRACKET COOLANT TANK
51 045764 1 SCREW HHTT M4-0.7 X 8 BP
52 065852 1 SPRING CLIP HOLDER .37-.62
53 * 069811 REF. CAP HEX 1/4 NPT BRASS
54 069860C 1 HOSE OIL DRAIN ASSY 21"
55 0C7649 1 CLAMP HOSE .38-.87
* ITEM 53 IS INCLUDED WITH ITEM 64.
BEARING PRESS NOTE:
APPLY LOCTITE 620 BEARING RETAINMENT
COMPOUND TO BEARING SURFACE ON ITEM 37
PRIOR TO PRESSING ITEM 28 ONTO ITEM 37.
ALSO APPLY LOCTITE 620 BEARING RETAINMENT
COMPOUND TO THE OUTSIDE OF 28 PRIOR TO
INSTALLING ITEM 28 INTO ITEM 38.
