Fein Power Tools
BLs 2.5 Parts List
Item Item Number Description Reqd.
10 3-19-01-109-02-4 MOTOR HOUSING 1
20 3-28-16-051-00-1 SWITCH ROD 1
30 3-28-05-152-00-9 SLIDING BUTTON 1
40 5-1-272-004-11-9 FIELD COIL 1
50 4-30-70-014-00-0 SCREW 2
60 3-14-28-114-00-8 AIR CONDUCTING RING 1
70 3-07-12-087-01-5 BRUSH HOLDER 2
75 3-07-17-193-00-0 BRUSH CONNECTION 2
80 3-07-11-129-00-9 CARBON BRUSH 2
90 4-30-70-015-00-4 SCREW 2
100 3-07-01-060-00-0 REVERSING SWITCH 1
120 3-07-22-178-01-6 CAPACITOR 1
130 3-24-31-026-00-9 CABLE CLAMP 1
140 4-30-70-001-00-6 SCREW 2
150 3-24-27-108-01-6 COVER 1
160 4-30-70-003-00-3 SCREW 1
170 4-30-70-016-00-7 SCREW 2
180 3-07-07-101-01-2 CABLE 1
190 3-14-13-164-00-9 CABLE PROTECTING SLEEVE 1
250 5-3-272-005-11-5 ARMATURE 1
300 4-17-01-001-17-2 BALL BEARING 2
310 3-26-12-125-00-0 PACKING RING 1
330 3-15-06-353-00-7 INTERMEDIATE HOUSING 1
340 3-06-10-033-00-0 GASKET 1
350 3-36-57-105-00-2 GEAR WHEEL 41T 1
360 4-02-21-003-00-6 FITTING KEY 1
370 4-26-16-034-00-7 LOCKING RING 1
380 4-17-01-202-01-8 BALL BEARING 1
390 3-37-57-014-00-7 SPUR WHEEL 15T 1
400 3-36-57-167-00-3 GEAR WHEEL 29T 1
410 4-02-42-006-00-7 CYLINDRICAL PIN 1
420 3-13-08-076-00-9 GEAR HOUSING 1
430 3-13-08-077-00-3 PLUNGER 1
440 3-13-08-078-00-1 BOLT 1
460 3-13-08-079-00-5 SLEEVE 1
470 3-01-09-138-00-8 FOOT 1
480 6-36-01-101-00-9 CUTTER BLADE 2
490 3-34-05-027-00-6 ECCENTIC SHAFT 1
500 3-13-08-080-00-7 CONNECTING ROD 1
510 3-26-01-225-00-3 RING 1
520 4-17-01-202-01-8 BALL BEARING 2
530 4-17-15-032-00-3 NEEDLE CAGE 1
540 4-17-01-006-02-8 BALL BEARING 1
550 4-17-01-007-03-8 BALL BEARING 1
560 4-30-35-013-05-8 SCREW 1
570 4-30-35-014-05-6 SCREW 1
580 4-30-13-042-12-7 SCREW 1
590 4-30-45-044-05-1 PIN SCREW 1
600 4-26-16-001-00-5 LOCKING RING 1
640 4-30-70-026-00-6 SCREW 4
660 4-30-33-015-05-2 SCREW 2
670 4-06-11-001-00-2 PACKING RING 2
680 3-02-29-159-00-1 GUARD 1
690 4-30-35-013-05-8 SCREW 2
700 4-24-45-002-05-3 LOCKING RING 2
