Specications
armrests, integral safety switch, and seat vibration
isolation system.
Optional seat accessories for units with standard
seats:
– Custom ride suspension system to enhance
Standard Seat. Adds approximately 3 inches
(7.6 cm) to seat height.
– Deluxe suspension seat with high back,
(dampened, adjustable spring suspension),
armrests, and integral safety switch. Adds
approximately 1/2 inch (1.3 cm) to seat height.
• Mounting: Adjustable fore and aft on seat tracks.
• Armrests: Molded ip-up armrests.
• Seat Safety Switch:
Integrated seat switch. Time delay seat switch
eliminates rough ground cut-outs.
Hydrostatic Ground Drive System
• Two unitized hydrostatic transmissions:
Hydro Gear ZT3100
• Hydraulic Oil Type: Exmark Premium Hydro Oil.
• Hydraulic Oil Capacity: 7.7 oz (2.3 L) per side
• Hydraulic Filter: P/N 109-3321
• Speeds:
– 0-8 mph (12.9 km/hr) forward.
– 0-5 mph (8.0 km/hr) reverse.
• Drive wheel release valves allow machine to be
moved when engine is not running.
Tires & Wheels
Drive Front Caster
Pneumatic (Air
lled)
Pneumatic (Air
lled)
Quantity
2 2
Tread
Turf Master Smooth
Size 22 x 9.50-12 13 x 5.00-6
Ply Rating
4 4
Pressure
13 psi (90 kPa) 13 psi (90 kPa)
Cutting Deck
• Cutting Width:
– 44 inch Deck: (111.8 cm)
– 48 inch Deck: (121.9 cm)
– 52 inch Deck: (132.1 cm)
• Discharge: Side
• Blade Size:
– 44 inch Deck: 22.25 inches (56.5 cm) – (2 ea.)
– 48 inch Deck: 16.25 inches (41.3 cm) – (3 ea.)
– 52 inch Deck: 18.00 inches (45.7 cm) – (3 ea.)
• Blade Spindles: Solid steel spindles with .98 inch
(25 mm) I.D. bearings.
• Deck Drive: “B” Section belt with self-tensioning
idler.
• Electric clutch: 175 ft-lb Mag Stop
• Deck: Full oating deck is attached to out-front
support frame. Anti-scalp rollers provide
maximum turf protection. Deck design allows for
bagging, mulching or side discharge.
– 44 inch Deck: 2 anti-scalp rollers
– 48 inch Deck: 3 anti-scalp rollers
– 52 inch Deck: 3 anti-scalp rollers
• Deck Depth:
– 44 inch Deck: 5.0 inches (12.7 cm)
– 48 inch Deck: 5.0 inches (12.7 cm)
– 52 inch Deck: 5.0 inches (12.7 cm)
• Cutting Height Adjustment:
Foot activated lever is used to adjust the cutting
height from 1 1/2 inch (3.8 cm) to 5 inches (12.7
cm) in 1/4 inch (6.4 mm) increments.
• Mulching Kit: Optional.
Dimensions
Overall Width:
44 inch
Deck
48 inch
Deck
52 inch
Deck
Without
Deck
45.8 inches
(116.3 cm)
45.8 inches
(116.3 cm)
45.8 inches
(116.3 cm)
Deector
Up
48.2 inches
(122.4 cm)
50.7 inches
(128.8 cm)
54.2 inches
(137.7 cm)
Deector
Down
56.4 inches
(143.3 cm)
59.5 inches
(151.1 cm)
64.3 inches
(163.3 cm)
16
