OCDWB01 ASSEMBLY
- 3 -
Item
Part No.
Description
Qty.
1 116-1504 Asm, Mount..........................................1
1:2 1-353050 Pin, Mounting .......................................1
1:3 1-806323 Rollpin ..................................................1
2 3231-2 Bolt, Carriage 3/8-16 x 1.......................2
3 104-8301 Nut, Nyloc 3/8-16 Flg............................2
4 116-2358 Gate, Link Frame..................................1
4:2 98-5954 Decal, Danger ......................................1
5 116-1543 Pivot, Control Cable..............................2
6 116-1544 Shim, Control Cable .............................1
7 116-1545 Clamp, Control Cable ...........................1
8 116-2745 Cable, Control ......................................1
9 3250-12 Screw, PPH #10-24 x 1/2 .....................2
10 3296-12 Nut, Nyloc #10-24 Thin.........................2
11 1-806003 Hairpin, Cotter ......................................3
13 116-2942 Bracket, Control Mount.........................1
14 116-2361 Control Handle Asm .............................1
15 325-5 Screw, HH 1/2-13 x 1 1/4......................1
16 3296-45 Nut, Nyloc 1/2-13 Thin..........................1
17 103-5009 Disc, Friction ........................................2
18 103-5018 Washer, Spring Disc.............................3
Item
Part No.
Description
Qty.
19 109-5151 Deflector, Discharge............................. 1
20 116-2229 Pin, Chute............................................ 1
21 116-0962 Spring, Torsion.....................................1
22 3272-1 Pin, Cotter 1/16 x 1/2............................1
23 116-2941 Bracket, Handle Mount......................... 1
24 3230-18 Bolt, Carriage 5/16-18 x 5/8.................. 1
25 116-2223 Pin-Clevis.............................................1
26 116-2222 Bracket-Mounting................................. 1
27 3296-29 Nut, Nyloc 5/16-18 ...............................1
28 116-2469 Strap-Velcro Cable Tie.........................2
29 116-1510 Asm, Gate............................................1
29:2 116-1509 Gate..................................................... 1
29:3 114439 Rivet, Pop ............................................ 3
30 116-2792-01 Brkt, Chute Front.................................. 1
31 1-353054 Latch-Catcher, Grass........................... 1
32 323-6 Screw, HH 3/8-16 x 1 ...........................3
33 3296-39 Nut, Nyloc 3/8-16 ................................. 3
34 1-603727 Clip, Loom............................................ 1
35 116-3226 Shim..................................................... 1
Exmark red touch up paint (spray paint – P/N 1-850337 - .6 oz liquid bottle – P/N 103-9140).
