10
setting. Assure pin on adjusting lever engages
notch in mower housing wear plate. Adjust all
wheels to the same setting.
POTENTIAL HAZARD
• Adjusting height-of-cut levers could bring
hands into contact with moving blade.
WHAT CAN HAPPEN
• Contact with blade could cause serious
personal injury.
HOW TO AVOID THE HAZARD
• Stop engine and wait for all moving parts
to stop before changing height-of-cut.
• Do not put fingers under housing to lift
mower when adjusting height-of-cut levers.
Mulching Tips
General Tips
Follow these instructions whether cutting grass or
leaves for the best cutting results and lawn
appearance:
• Maintain a sharp blade
throughout the cutting
season. Periodically file down nicks on blade.
• Only mow dry grass or leaves. Wet grass and
leaves tend to clump on yard and may cause
mower to plug or engine to stall. They also may
be slippery to walk on and could cause you to
slip and fall.
POTENTIAL HAZARD
• Wet grass or leaves can cause you to slip
and contact blade.
WHAT CAN HAPPEN
• Blade contact can seriously injure you.
HOW TO AVOID THE HAZARD
• Mow only in dry conditions.
• Set engine speed to fastest position. Maximum
horsepower provides best cutting results.
• Clean clippings or leaves from underside of
mower deck after each mowing.
• Keep engine in good running condition. Cutting
and recutting requires more horsepower.
• Clean air filter more frequently. Cutting and
recutting stirs up more clippings and dust which
clogs the air filter and reduces engine
performance.
Cutting Grass
• Grass grows at different rates at different times
of the year. In the heat of the summer, it is
generally best to cut grass at the 1-#/4”, 2-!/4” or
2-#/4” height-of-cut settings (Fig. 14). Only
about !/3 of the grass blade should be cut off.
Cutting below the 1-#/4” setting is not
recommended unless grass is sparse or it is late
fall when grass growth begins to slow down.
• When cutting grass over six inches tall, you may
want to first mow using the highest height-of-cut
setting and a slower walking speed; then mow
again at a lower setting for best lawn appearance.
If grass is too long and leaves clumps on top of
lawn, mower may plug and cause engine to stall.
• Alternate mowing direction. This helps disperse
clippings over lawn for even fertilization.
If the finished cut lawn appearance is unsatisfactory,
try one or more of the following:
• Sharpen the blade.
• Walk at a slower pace while mowing.
• Raise the height-of-cut setting on your mower.
• Cut grass more frequently.
• Overlap cutting swaths instead of cutting a full
swath with each pass.
• Mow across the marginal areas a second time.
• Set height-of-cut on front wheels one notch
lower than rear wheels. (example: set front
wheels at 1-#/4” setting and rear wheels at 2-!/4”
setting)
