Setup
Setup
WARNING
Operating a FrontRunner tractor without an
approved Exmark front mount attachment
increases the possibility of forward tip over.
Tip-over could cause serious injury or death.
When operating a FrontRunner tractor
without an approved Exmark front mount
attachment, observe the following:
• Limit operation to minimum required to
install a different front mount attachment.
• Minimize speed and use extreme caution.
• Only operate on a at level surface.
• Do Not operate up or down a trailer ramp.
• Avoid sudden acceleration or deceleration.
Assemble Deck to
FrontRunner
Important: Do Not transport Frontrunner
tractor without and approved Exmark front
mount attachment.
1. Stop the engine, wait for all moving parts to stop,
engage the parking brake, and remove the key.
2. Rotate the fold lock lever, located on the deck, in
the unlocked position (Figure 3).
Figure 3
1. Fold lock lever shown in the unlocked position
3. On the tractor, remove the two retaining pins
on hitch latches so the latches can actuate freely.
Raise the oor pan and lock in upright position
(Figure 4).
Figure 4
1. Remove the retaining pins from both hitch latches
2. Floor pan shown locked in the upright position
4. Align the front frame of the mower deck to the
Frontrunner tractor hitch.
5. Manually lift up on the hitch to get the bars on the
front frame started into the receivers of the hitch.
6. Push the front frame towards the tractor until the
two hitch latches seat into the “secure” position.
11
