Operation
engaged. The unit must be tied down and brake
engaged when transporting.
The park brake must be disengaged to move speed
control out of neutral or engine will kill.
For manual start engines: The park brake must be
disengaged before the PTO is engaged or the engine
will kill.
Ignition Switch
Located on the left side of the control console.
The ignition switch is used to start and stop the
engine. The ignition switch has three positions,
“Off ”, “On” and “Start”. Insert key into switch
and rotate clockwise to the “On” position. Rotate
clockwise to the next position to engage the starter
(key must be held against spring pressure in this
position). Operator must have speed control lever in
neutral, OPC levers depressed and PTO disengaged
to start engine. When engine starts, release key.
Fuel Valve
Located on the LPG fuel tank.
The fuel valve is used to open and close the fuel
supply when the machine is not in use, during
transport to and from the jobsite, and when parked
inside a well-ventilated building.
Rotate the fuel valve clockwise to turn off the fuel.
Rotate fuel valve counter-clockwise to turn on the
fuel.
Drive Wheel Release Valves
Located on the left rear corner of the hydrostatic
pumps.
Drive wheel release valves are used to release the
hydro-static drive system to allow the machine to be
moved by hand without the engine running.
With a 5/8 wrench, turn both valves one turn
counterclockwise to release the drive system.
Turn clockwise to reset the drive system. Do Not
overtighten.
Tracking Adjustment Knob
Located on the right-hand side of the rear of the fuel
tank support.
The knob can be adjusted so that machine will “track”
straight ahead with the drive levers released.
PTO Engagement
Located on the left side of the upper handle.
To engage the blades, push the lever forward, or away
from the operator, until the linkage locks over-center.
To disengage the blades, pull the lever to the rear,
or towards the operator.
For manual start engines: The park brake must be
disengaged before the PTO is engaged or the engine
will kill.
LPG Cylinder Bracket
The bracket is located on the engine deck.
The LPG cylinder bracket is used to fasten the
removable LPG tank to the mower.
Fuel Gauge
Located on the LPG fuel tank.
This gauge monitors the amount of liquid LPG in
the fuel tank.
Safety Pressure Relief Valve
Located on the LPG fuel tank.
The safety pressure relief valve relieves the excess
pressure in the LPG tank.
Important: This valve has a protective plastic
cap that should NEVER be removed. If the
cap is damaged or missing, contact trained and
qualied personnel immediately.
Pre-Start
LPG tanks supplied from Exmark Do Not contain
LPG fuel. Have the LPG tanks lled by trained and
qualied personnel. For best results, use clean, fresh
HD5 grade propane.
Do Not allow the LPG tanks to be overlled.
Overlling LPG tanks builds excess pressure within
the tank which causes the relief valve to open.
Make sure you understand the controls, their
locations, their functions, and their safety
requirements.
20
