Note: 1. Subject to change without notice.
2. Reference DOC-1237 REV A.
Specification, 2005, Triad II
Doc-1215 Rev -B
Rev Date: 1/31/05
2005 Triad II Specifications
Dimension One Spas
General Domestic (60Hz) Part # Export (50Hz) Part #
Shape Rectangular Rectangular
Ultralife™ / Granitex™ Ultralife™ / Granitex™
/ Geloy® / Geloy®
Height 30 ½ in. 77 cm
Width 83 ½ in. 212 cm
Length 66 ½ in. 169 cm
Corner Radii 16 in. 41 cm
Seating Capacity 3+ 3+
Water Capacity 200 Gallons 757 Liters
Dry Weight 640 lbs 291 kg
Shipping Weight 640 lbs 313 kg
Full Weight 2310 lbs 1048 kg
Skirt Material Wood or Synthetic Wood or Synthetic
Poly Floor Yes Yes
Water System
Motor Size – Peak(Continuous) HP 4.0 (2.5) HP 3.6 (2.0) HP
# Pumps/Speed One / Dual 01562-23A One / single 01562-29A
Plumbing Systems 1 1
Pump Returns 2 01510-559 2 01510-559G
Typhoon Jets 0 0
VCR Jet
®
- Air Adjustable/Directional 4 01510-418 4 01510-418G
VCR Jet
®
- Rotator 7 01510-415 7 01510-415G
VCR Jet
®
- Mini Rotator 2 01510-445 2 01510-445G
VCR Jet
®
- Mini Directional 6 01510-444 6 01510-444G
VCR Jet
®
- Mini Directional in NFJ 4 01510-595 4 01510-595G
VCR Jet
®
- Euro Directional 0 0
Ozone Jet 1 01510-201 1 01510-201G
Heater Return Jet 1 01510-275 1 01510-275G
Filters/Coverage 2 / 75 sq. ft. (2) 01561-00 2 / 6.97 sq. meters (2) 01561-00
Water Treatment System Ultra Pure™ Ultra Pure™
Gate Valves 2 01522-30 2 01522-30
Diverter Valves 0 0
Floor Drains 1 01510-231 1 01510-231G
Skimmer 8” Weir 01510-137 20 cm Weir 01510-137G
Electrical System
Voltage 240 240
Amperage 40/30 1X16 / 2X16 / 1X32
Heater FastFlo 2.7,4.0,5.5 kW 01781-20 FastFlo 2.9 kW 01781-20
Thermostat Electronic Electronic
Light 1 with optional LED 01512-003 (O) 1 with optional LED 01512-003 (O)
Control System MSPA-MP-D12 01710-1008 MSPA-MP-D11-CE 01710-1008E
Upper Control Scrolling Message Center 01580-0001 Scrolling Message Center 01580-0001
Auxiliary Upper Control No No
Programmable Yes Yes
Special Features
Dynamic Massage Sequencer PCA 01710-1001 PCA 01710-1001
w/ control panel UCP 01560-1005 UCP 01560-1005
NeckFlex
®
Jet Pillows 1 01510-598 1 01510-598
Headrest Pillows 2 01510-593 2 01510-593
Cup Holders 2 2
Tactile Therapy Floor pedestal Floor pedestal
Shell Material
Yes Yes
