Dimension One Spas – @Home Series Owner’s Manual
10
Control Function
8
8.TEMPERATURE Buttons
Control the water temperature with the Up (+) and Down (-) Buttons. Push a
button once to change the temperature by one degree, or hold it down to
rapidly change it by many degrees. The temperature can be set no higher than
104 ° F (40° C).
While setting the temperature, the Set Point light on the Control Panel will
glow to indicate that the display is showing the desired Set Temperature and
not the actual temperature.
After the desired temperature is set, the Display Window will revert to
showing the actual water temperature. The hot tub will heat to the new Set
Temperature automatically.
9
9. PROGRAM Button
Push PROGRAM to begin the process of programming the spa functions. See
the section on “Programming the Spa Functions” for details.
To initiate the programming sequence at any time, hold PROGRAM for 3
seconds. If within 10 seconds no button is pushed, the spa will automatically
exit the programming sequence and revert to the pre-set factory default
settings. To exit the programming sequence at any time, do not press any
button for 10 seconds. Any programming changes made up to that point are
saved.
Programming the Spa Functions
To initiate the programming sequence at any time, hold PROGRAM for 3 seconds. If within 10 seconds no button is
pushed, the spa will automatically exit the programming sequence and revert to the pre-set factory default settings. To
exit the programming sequence at any time, do not press any button for 10 seconds. Any programming changes made up
to that point are saved.
Filter Cycle Duration
Pressing PROGRAM sets the Filter Cycle Duration. This tells the spa how long to run during each filter cycle. Use the
UP or DOWN to choose from 60, 90, 120, 150, or 180 minutes. The factory default is 60 minutes. After setting the
desired duration, press the Program button again to move to the next step.
Number of Filter Cycles
After setting the Filter Cycle Duration set the Number of Filter Cycles the spa will run each day. Use UP and DOWN to
choose 1, 2, 3, or 4 cycles per day. The factory default is 2 times per day. Then press PROGRAM to move on to the next
step.
NOTE: The spa considers the “Start Time” of the first filter cycle to be one minute after its power is turned on. To
change the starting time of the first filter cycle and all following cycles, turn the spa power off and then on at the desired
time of day to reset it. All other programs will need to be reset because they will revert to factory settings.
