PARTS LIST
Craftsman Engine Model LH318SA-156587 For Snow Thrower Model 247.881900
Ref. No. Part No. Description
0 640052 Carburetor
1 631776A Throttle Shaft & Lever Assembly
2 631970 Throttle Return Spring
6 631778 Throttle Shutter
7 650506 Shutter Screw
10 632112 Choke Shaft & Lever Assembly
14 632174 Choke Shutter
15 630735 Choke Positioning Spring
16 632164 Fuel Fitting
17 650417 Throttle Crack Screw/Idle Speed Screw
18 630766 Tension Spring
20 640016 Idle Restrictor Screw
20A 640053 Idle Restrictor Screw Cap
25 631951 Float Bowl Ass’y (Incl. 32 & 33)
27 631024 Float Shaft
28 632765 Float
29 631028 Float Bowl “O” Ring
30 631021 Inlet Needle, Seat & Clip (Incl. 31)
31 631022 Spring Clip
32 27136A Bowl Drain Assembly
33 27554 Drain Plunger Gasket
36 640005 Main Nozzle Tube
37 632547 “O” Ring, Main Nozzle Tube
40 640055 High Speed Bowl Nut
44 27110 Bowl Nut Washer
47 630748 Welch Plug, Idle Mixture Well
48 631027 Welch Plug, Atmospheric Vent
60 632760 Repair Kit
11
6
29
20A
47
17
2
15
16
10
1
18
7
20
31
7
40
44
37
36
28
37
60
32
32
33
25
30
27
