ENGLISH 100216
SPECIFICATIONS
Engine Specifications
– Model ...................... YF172FD-010
– Displacement .......................224cc
– Type ........................4-Stroke OHV
– Start Type .........................Recoil
Oil
Use 10W-30 automotive oil.
Oil capacity is up to 0.6 qt. (0.6 L).
DO NOT OVERFILL.
Please reference the following chart for recommended
oil types for use in the generator.
Generator Specifications
– Model ...........................100216
– Rated Wattage ..................3650 Watts
– Starting Wattage .................4500 Watts
– AC Load ...................... 120/240 V
– Phase ............................Single
– Frequency .........................60 Hz
– Fuel Capacity .................3.4 gal. (13 L)
– Gross Weight ..............104.7 lb. (47.5 kg)
– Net Weight ................... 97 lb. (44 kg)
– Height ................... 19.6 in. (49.9 cm)
– Width ...................18.1 in. (46.1 cm)
– Length. . . . . . . . . . . . . . . . . . . . 23.2 in. (59 cm)
Fuel
Fuel capacity is 3.4 gal. (13 L). Use regular unleaded
gasoline with a minimum octane rating of 85 and an
ethanol content of less than 10% by volume.
An Important Message About Temperature
Your Champion Power Equipment product is designed
and rated for continuous operation at ambient
temperatures up to 40°C (104°F). When your product is
needed your product may be operated at temperatures
ranging from -15°C (5°F) to 50°C (122°F) for short
periods. If the product is exposed to temperatures
outside this range during storage, it should be brought
back within this range before operation. In any event,
the product must always be operated outdoors, in a
well-ventilated area and away from doors, windows and
other vents.
Full Synthetic 5W-30
Degrees Celsiusº
(Outside)
(Outside)
Degrees Fahrenheitº
Weather will affect engine oil and engine
performance. Change the type of engine oil used
based on weather conditions to suit the engine
needs.
NOTE
Maintenance Valve Clearance
– Intake: 0.13 – 0.17 mm (0.005 – 0.007 in.)
– Exhaust: 0.18 – 0.22 mm (0.007 – 0.009 in.)
Note: Tech bulletin regarding the valve adjustment
procedure is on www.championpowerequipment.com.
Spark Plugs
OEM spark plug: NHSP F6RTC
Replacement spark plug: NGK BPR6ES or equivalent
Make certain the spark plug gap is 0.7 - 0.8 mm or
(0.028 - 0.031 in.).
