PART NO. DESCRIPTIONREF NO QTY.
Handles Group
Footnotes
BOLT, Carriage, Short Neck, 5/16-18 x 1-1/2, G5 0020 1931337SM 2
NUT, Hex Flange, Esna, 1/4-20 0030 2860694SM 1
IGNITION KEY, Pair 0040 7011138YP 1
WIRE TIE, 11 Inch Std Black Nylon 0050 7024649YP 2
GUIDE, Rope 0060 7028488MA 1
SWITCH, ES Start / Run 0070 7028765YP 1
WASHER, Internal Tooth Lock, 5/16” 0080 7090391SM 4
NUT, 5/16-18 Hex Large Flange Center Lock 0090 7090951SM 2
BOLT, Curved Head Square Neck, 5/16-18 x 2”, GR 2 0100 7091189YP 2
SCREW, #8-16 Torxplus Recessed Pan Head, Twin Helix 0110 7100225YP 4
NUT, Electric Start 5/8-32 0120 7100329YP 1
CAP, Electric Start 0130 7100330YP 1
WIRING HARNESS, Electric Start 0150 7103676YP 1
CONTROL BOX ASSEMBLY 0160 7103890YP 1
CABLE, Bail, 21", WBM, Brute, Electric Start 0170 7103973YP 1
BAIL, Brute SP, Operator Presence Control 0220 7101731AMA 1
HANDLE, Lower, 21” Rear Discharge 0230 7300592AMA 1
HANDLE, Upper, Propelled 0240 7300676AMA 1
PLATE, Control Panel 0250 7300130AMA 1
BOLT, Carriage, 5/16 - 18 x 3/4 0260 340720MA 2
KNOB, 5/16-18, Wing, Black 0270 7035744YP 4
The above parts group applies to the following Mfg. Nos.:
5
Briggs & Stratton Power Porducts Group
Copyright © by Briggs & Stratton Corporation
Milwaukee, WI, USA. All rights reserved
2011
7800822 - BTXPV22700E
