REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
205300
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
3986--17 Assemblies include all parts shown in frames. 03/19/2009
17
441 797125 Bracket--Oil Fill
Used on Type No(s).
0319.
445 491588S Filter--Air Cleaner
Cartridge
445A 695302 Filter--Air Cleaner
Cartridge
Used on Type No(s).
0113, 0118, 0119,
0120, 0122, 0123,
0197, 0213, 0218,
0229, 0281, 0303,
0304, 0305, 0307,
0310, 0311, 0313,
0314, 0315.
446 794941 Spring--Retainer
455 794867 Cup--Flywheel
456 692299 Plate--Pawl Friction
459 281505S Pawl--Ratchet
467 691668 Knob--Air Cleaner
Used on Type No(s).
0113, 0118, 0119,
0120, 0122, 0123,
0197, 0213, 0218,
0229, 0281, 0303,
0304, 0305, 0307,
0310, 0311, 0313,
0314, 0315.
474A 695730 Alternator
(3 Amps DC)
474D 695466 Alternator
(10 Amp Regulator)
493A 691177 Bracket--Mounting
(Oil Sensor)
493B 794782 Bracket--Mounting
(Oil Sensor)
500A 792613 Washer
(Key Switch)
501 691185 Regulator
503 691532 Strap--Starter
504 695383 Washer Set--Friction
505 691251 Nut
(Governor Control
Lever)
510 693699 Drive--Starter
513 692024 Clutch--Drive
522 697689 Plug--Dipstick/Fill
Used on Type No(s).
0118, 0119, 0120,
0122, 0123, 0178,
0194, 0214, 0229,
0282, 0313.
523 695344 Dipstick
524 691876 Seal--Dipstick Tube
525 695343 Tube--Dipstick
526 690297 Screw
(Regulator)
529 791822 Grommet
535 696315 Filter--Air Cleaner
Foam
Used on Type No(s).
0173, 0241, 0317.
544 692034 Armature--Starter
552 694674 Bushing--Governor
Crank
562 793216 Bolt
(Governor Control
Lever)
564 699492 Screw
(Control Cover)
(18.67 mm Long)
564A 699491 Screw
(Control Cover)
(10.75 mm Long)
Used on Type No(s).
0118.
577A 690795 Cable--Starter
578 692306
Wire Assembly
Used
on Ty pe No(s).
0204, 0210, 0216,
0242, 0317, 0319,
1185, 1313.
578A 790948 Wire Assembly
579 691029 Nut
(Starter Cable)
597 691696 Screw
(Pawl Friction Plate)
601 791850 Clamp--Hose
604 699066 Cover--Control
Used on Type No(s).
0118.
604A 791752 Cover--Control
Used on Type No(s).
0172, 0194, 0205,
0217, 0241, 0319.
608 695287 Starter--Rewind
613 794846 Screw
(Muffler)
613A 794848 Screw
(Muffler)
613B 794844 Screw
(Muffler)
614 691620 Pin--Cotter
(Governor Crank)
615 694676 Retainer--Governor
Shaft
(Governor Gear)
(Used Before Code
Date 08021500).
616 795758 Crank--Governor
621 692310 Switch--Stop
622 794839 Washer
(Heat Shield)
627A 792608 Bracket--Stopswitch
632 695917 Spring/Link--
Mechanical Governor
(Used Before Code
Date 08071800).
-- -- -- -- -- -- N o t e -- -- -- -- -- --
695917 Spring/Link--
Mechanical Governor
(Used Before Code
Date 08082000).
Used on Type No(s).
0113, 0118, 0119,
0120, 0122, 0123,
0197, 0213, 0218,
0229, 0281, 0303,
0304, 0305, 0307,
0310, 0311, 0313,
0314, 0315.
695917 Spring/Link--
Mechanical Governor
(Used Before Code
Date 09020900).
Used on Type No(s).
0115, 0140, 0172,
0178, 0194, 0205,
0212, 0214, 0215,
0216, 0217, 0280,
0538, 1207, 1232.
Not for
Reproduction
