MAINTENANCE
RB60/72 02/11 Maintenance Section 5-5
© 2011 Alamo Group Inc.
MAINTENANCE
Gearbox Lubrication
The gearbox should be full (18 ounces) 0.54 liters
and not require additional lubricant unless the box
is cracked or a seal is leaking. It is recommended
that the hex oil level check plug (Figure MntP-R-
0020) be removed to check oil level after every 8
hours of operation. If required, oil should be added
until it runs out hole.
Recommended lubricant is Multi-purpose gear oil,
P/N 00786250.
NOTE: Make sure mower is level when checking oil
in the gearbox. Gearbox capacity is 1 Quart.
NOTE: Overfilling of Gearbox will cause pressure to build up and cause Grease Seals to leak.
DRIVELINE LUBRICATION
Grease Fittings are located on the Cross Assembly
of each U-Joint and on the telescoping tubes.
Grease the U-Joint after each 8 hours of use.
Figure MntP-R-0021. Do not force grease through
the Needle Cup Assemblies. Grease the
telescoping tubes after every 8 hours use. To
grease profile tube, disconnect drive from PTO and
pull halves apart. Pump grease into outer profile
tube and reinstall together. Lube Slide Collar weekly
with WD40 or equivalent weight oil. Figure Mnt-R-
0037.
