Filter
Top Products
3A
2
Pivot Ball
Showerhead
Bracket
Large Nut
Wrench for
Pivot Ball
(included)
Hand Held
Showerhead
ENGLISH
COMPONENTS
Your showerhead comes with the respective hardware sets
shown below.
FN 20011364-F AC
Note: Drawings may not match your product. Remarque: Les illustrations peuvent ne pas
correspondre a´votre produit. Nota: Es posible que los dibujos no coincidan con su producto.
Easy Select
Showerhead
Pomme de douche
Waterpik
®
Easy Select
™
Cabezal de ducha
Waterpik
®
Easy Select
™
Instruction Manual
Manuel d’instructions
Manual de instrucciones
Thank you for purchasing this Waterpik
®
Easy Select
™
brand
Showerhead, and welcome to a new level of showering enjoyment!
Since we invented the massaging showerhead in 1973, we’ve been
constantly working to improve the showering experience for our
customer. Our latest generation shower technology delivers both pure
relaxation and rejuvenation with the selection at your finger tips.
INSTALLATION
1. Remove old showerhead.
2. Remove large nut from
Easy Select
™
bracket
and remove pivot ball.
NOTE: This nut and bracket have a
left handed thread. The large nut
tightens when turned clockwise as
viewed from the front of the bracket.
Tighten securely. (2)
3. Place large nut over
shower pipe (narrow
end toward wall).(3A)
™
4
7
3B
5
Waterpik
®
brand showerheads are equipped with an OptiFLOW
®
regulator
that limits maximum water flow to 2.5 gallons per minute at 80 psi as
mandated by U.S. federal law.
The flow regulator may be removed for cleaning debris to improve water
flow in the showerhead. To remove, unscrew filter screen from pivot ball
by turning counterclockwise. Remove regulator with needle-nose pliers
and replace filter screen.
OPERATION
Turn spray selector on handle
in either direction to control
spray pattern.
Thread pivot ball onto shower
pipe and hand tighten clockwise
to a snug fit. (3B)
4. Use wrench provided to tighten
pivot ball to pipe until it is
secure.
5. Attach bracket by hand tighten-
ing the large nut to the threaded
back of the bracket. (5)
6
6. Hose Attachment: Hand
tighten hose end to bracket
and handle. Do not use pli-
ers, wrench, or pipe tape to
connect hose ends to show-
erhead or bracket.
7. If showerhead or bracket
becomes loose during use,
re-tighten large nut as
described above.
CARE AND CLEANING
• Clean filter screen at least once a year or whenever you notice a drop
in water pressure. To clean, remove bracket from large nut. Remove
the pivot ball from the shower pipe and gently brush the filter screen,
located in the pivot ball. You can also back flush the filter screen by
holding the pivot ball under a running faucet with the small end (non-
threaded) up in the water stream. To replace showerhead, follow steps
2-4 of installation.
• To clean mineral deposits, gently rub the rubber nozzles on the face of
the showerhead to dislodge. For deeper cleaning, remove showerhead
and place in 1-1½ cups of white vinegar for 2-3 hours. Reattach
showerhead and run in all modes for 1-2 minutes to clean out vinegar.
Vacuum Breaker (some models)
Vacuum breakers are required on hand-held showers in the State of
Wisconsin and the City and County of Los Angeles, California, by plumbing
code in order to protect water supplies from potential back-flow.
The vacuum breaker (located within the bracket) may discharge a small
amount of water when you turn on your shower. It will also drain a
small amount of water when you turn off your shower. Both are normal
operative conditions.
LIMITED LIFETIME WARRANTY
Water Pik, Inc. warrants to the original purchaser of this product that it is
free from defects in material and workmanship for as long as the original
purchaser owns this product. Water Pik, Inc. will replace any part of the product
which in our opinion is defective, provided that the product has not been abused,
misused, altered or damaged after purchase. (This includes damage due to
use of tools or harsh chemicals.) In the event an item has been discontinued
we will replace with what we deem to be the closest product. Water Pik, Inc. is
not responsible for labor charges, installation, or other consequential cost. The
responsibility of Water Pik, Inc.
shall not exceed the original purchase price of
the product. This warranty gives you specific legal rights. You may also have
other rights that vary where you reside. Save your receipt as proof of purchase is
required for warranty action.
Have any questions or need assistance?
In the U.S., call our toll-free
Customer Assistance Line,
1-800-525-2774.
If in Canada call our toll-free
Customer Assistance Line,
1-888-226-3042
www.waterpik.com
If product malfunctions or becomes damaged, stop use and contact
Water Pik, Inc. for replacement.
