Northern Industrial Tools M1107C Log Splitter User Manual



Moving and Towing to Job Site
12
5. Put tow bar leg
UP
Move the tow bar leg to the “UP” position and lock. (The support leg must
remain in the up position during towing.)
6. Tow to desired
location
Tow log splitter carefully to desired work site.
(See “Before Each Use” section for instructions on selecting an appropriate work site)
Important safety instructions:
Added length. Be aware of the added length of the splitter.
Speed limit. Never tow this log splitter over 45 mph. Faster speeds may
result in loss of control.
Rough terrain. Drive slowly and take extra caution when traveling over
rough terrain.
On public roads. If towing on a public road, make sure to comply with
all local, state, and federal towing requirements. It is the sole
responsibility of the purchaser to obtain licensing, trailer lights, safety
chains or signage, as needed to comply.
Unattended. Turn off the towing vehicle before leaving the splitter
unattended.
Under the influence. Never tow or operate this splitter while under the
influence of alcohol, drugs, or medication
7. Lock leg down &
unhitch
Lock tow bar leg in the DOWN position and disconnect from vehicle.
NEVER operate log splitter while it is attached to the vehicle.
