1
Wireless Temperature Station
with Snooze Alarm
Model: CA85169 | Quick Setup Guide
INTRODUCTION: The Wireless Temperature Station features manual
set time, date, time alarm with snooze, indoor and outdoor temperature
with high and low outdoor temperature alarms. Current temperatures at
your fingertips!
SETUP INSTRUCTIONS STEP BY STEP:
STEP 1:
Remove battery cover from the Temperature Station. Slide tab down
and pull out to remove the battery
cover.
Insert 2 NEW AA batteries (not
included) into the back of the
Temperature Station. Observe the
correct polarity (see marking inside the
battery compartment).
The Temperature Station will light up
and show, indoor temperature.
Do Not Mix Old and New Batteries
Do Not Mix Alkaline, Standard,
Lithium or Rechargeable Batteries
STEP 2:
Ensure that the transmitter is within 10 feet of the
Temperature Station.
Remove battery cover from TX141-A transmitter: Slide
the battery cover down and lift off the front of the
transmitter.
Insert 2 NEW AA batteries into the transmitter. Observe
the correct polarity.
Within 3 minutes the Temperature Station will show readings in the
outdoor temperature area on the LCD.
Note: Allow the Temperature Station and the transmitter to stay
within 10 feet of each other for the first 15 minutes of set up.
SEARCH FOR TRANSMITTER:
After the batteries are inserted, the forecast station will search for
the outdoor temperature/humidity transmitter for 3 minutes.
The antenna symbol will flash during reception, and
temperature display will be dashes “---“.
The antenna symbol scroll during RF (radio frequency)
synchronization.
If synchronization fails once, the antenna will lose one bar.
If synchronization fails twice, the antenna will lose two bars.
If reception continuously fails to receive 5 times, the antenna symbol
will be shown as .
The antenna will show full display with successful RF
(radio frequency) reception.
TROUBLESHOOTING:
If the outdoor temperature is not displayed after three minutes, hold
the SENSOR SEARCH button on the temperature station for three
seconds to search for outdoor transmitter.
Next remove the battery cover from the TX141-
A transmitter then press the TX button to send
a signal.
If it still does not receive the outdoor
temperature, remove the batteries from both the temperature station
and the transmitter for 15 minutes repeat setup instructions from
step 1.
TIME/DATE:
The TIME/DATE button will move through the
program menu and confirm settings.
The UP arrow (on back) will increase a selected
value.
The DOWN arrow (on back) will decrease a
selected value.
Set Time and Date:
Hold the TIME/DATE button for three seconds to enter time set mode.
YEAR: The Year will flash, use the ARROW buttons to choose the
year, and press the TIME/DATE button to confirm and move to the
month.
MONTH: The Month will flash, use the ARROW buttons to choose
the month, and press the TIME/DATE button to confirm and move to
the date.
DATE: The Date will flash; use the ARROW buttons to choose the
date. Press the TIME/DATE button to confirm and move to 12/24
hour time format.
12/24-HOUR: The time format 12H will flash, use the ARROW
buttons to choose 12-hour or 24-hour time format and press the
TIME/DATE button to confirm and move to hour.
HOUR: The Hour will flash, use the ARROW buttons to choose the
hour, and press the TIME/DATE button to confirm and move to
minutes.
MINUTES: The Minutes will flash, use the ARROW buttons to
choose the minutes, and press the TIME/DATE button to confirm
and move to Fahrenheit/Celsius.
FAHRENHEIT/CELSIUS: °F or °C will flash. Use the ARROW
buttons to select Fahrenheit or Celsius. Press and release the
TIME/DATE button to confirm and exit the program menu.
Note: When no buttons are pressed for ten seconds the Temperature
Station will save the last change and default back to normal mode.
TIME ALARM
The TIME ALARM button moves you through alarm set
mode and confirms settings.
The UP arrow (on back) will increase a selected value.
The DOWN arrow (on back) will decrease a value.
