8 33734 Rev J 1/11
7. Place the Logs
a. RearLog
Therearlogissuppliedwithlocatingslotsinthe
baseofthelog.Locatetherearlogoverthelocating
tabsattherearofthetoppan.SeeFigure9.
Figure 9 - Rear Log Placement
b. FrontLog
Thefrontlogissuppliedwithnotchesinthebase
ofthelogtolocatethelogonthegrate.Lineup
thenotchesinthelogwiththegratebarsandpull
thelogforwarduntilitcomesintocontactwiththe
uprightportionofthegratebars.SeeFigure10.
c. TopRightLog
Thetoprightlogissuppliedwithlocatingslotsin
thebase ofthelog.Locate thelogoverthe two
locating pins found in the rear log and the front log.
SeeFigure11.
Figure 10 - Placing the Front Log
Figure 11 - Top Right Log
Figure 12 - Top Left Log
d. TopLeftLog
Thetopleftlogissuppliedwithalocatingtabthat
ts intoa notchon thetop of thefront log.See
Figure12.
