Harbor Freight Tools 95159 Blower User Manual



4-PIECE AIR
BLOW GUN SET
Air Blow Gun With Standard Nozzle and
Two Extensions
Die-cast Aluminum Frame Body; Steel Trigger Level;
Threaded Die-Cast Zinc Tips
Air Inlet: 1/4” - 18 NPT
Air Discharge: 3/32” Diameter
Maximum PSI: 110 PSI
Overall Dimensions: 4-1/2” L X 5-1/2” H X 7/8” W
OPERATING INSTRUCTIONS
1. Thread the nozzle or the needed extension onto the tip of the
Air Blow Gun.
2. Attach the Air Blow Gun to the air source hose. Set the air
compressor to 30 - 100 working PSI. Do NOT exceed 110 PSI.
3. Squeeze Air Blow Gun trigger to begin the flow of air.
4. Release Air Blow Gun trigger to stop the flow of air.
5. When finished, turn off the air compressor and then
disconnect Air Blow Gun from the air source hose
6. Only use clean and dry compressed air. Never use oxygen,
carbon dioxide, combustible gases or any other bottled gas
as a power source.
09/06 Made in China.
For technical questions and replacement parts, please call Harbor
Freight Tools at 1-800-444-3353
1. Always wear ANSI-approved safety goggles when working
with tools and equipment.
2. Keep out of the reach of children.
3. Store Air Blow Gun Set in a dry and secure location.
4. Do not exceed the maximum air pressure of 110 PSI.
5. Do not modify any part of the Air Blow Gun Set to perform
any task for which they were not designed.
6. Never point the Air Blow Gun at peoples or animals.
7. Save these warnings.
SPECIFICATIONS
ITEM
95159
